CAMSHAFTS
BRAKE CAMSHAFTS — STEERING AXLE
FOR MERITOR STEERING AXLES WITH 15” “Q” BRAKES - 1-1/2” OFFSET BACKING PLATE
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-9707
LH
1-3/16”
Meritor 2210J6614
8-1/2”
E-3876
E-3869
E-9708
RH
Meritor 2210X6732
E-5529
LH
1-3/16”
Meritor 2210C6737
9-1/4”
E-3876
E-3869
E-5530
RH
Meritor 2210D6738
E-9711
LH
1-3/16”
Meritor 2210L6746
9-9/16”
E-3876
E-3869
E-9712
RH
Meritor 2210M6747
FOR MERITOR STEERING AXLES WITH 15” “Q” BRAKES - 2” OFFSET BACKING PLATE
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-9713
LH
1-3/16”
Meritor 2210Q6725
7-13/16”
E-3876
E-3869
E-9714
RH
Meritor 2210R6726
E-9715
LH
1-3/16”
Meritor 2210E6739
9-13/32”
E-3876
E-3869
E-9716
RH
Meritor 2210F6740
E-9717
LH
1-3/16”
Meritor 2210Q6751
10-1/16”
E-3876
E-3869
E-9718
RH
Meritor 2210R6752
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
