CAMSHAFTS
BRAKE CAMSHAFTS — DRIVE AXLE
FOR EATON DRIVE AXLE
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT REPAIR
KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-2800
LH
1-3/8”
Eaton 1000087
8-9/16” E-2125
E-1887AHD
Extended service camshafts
CAN be used in place of
standard camshafts.
Standard camshafts CANNOT
be used in place of extended
service camshafts when sing
Extended service shoes and/
or linings.
Extended service camshafts
are .060 longer than their
standard counterpart to allow
for a special washer under
the head.
E-2799
RH
Eaton 1000088
E-5490
LH
1-1/8”
Eaton 7-808708
8-5/8” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-5491
RH
Eaton 7-808709
E-9763
LH
1-3/8”
Eaton 40547
10-5/32” E-2125
E-1887AHD
E-9764
RH
Eaton 40548
E-9767
LH
1-1/8”
Eaton 808072
10-9/16” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-9768
RH
Eaton 808073
E-9765
LH
1-3/8”
Eaton 45530
11-1/8” E-2125
E-1887AHD
E-9766
RH
Eaton 45531
E-1776
LH
1-1/8”
Eaton 70306
11-1/2” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-1775
RH
Eaton 70307
E-5492
LH
1-3/8”
Eaton 7-806526
11-1/2” E-2125
E-1887AHD
E-5493
RH
Eaton 7-806527
E-2787
LH
1-1/8”
Eaton 71306
12-7/16” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-2786
RH
Eaton 71307
E-9769
LH
1-3/8”
Eaton 808290
12-1/2” E-2125
E-1887AHD
E-9770
RH
Eaton 808291
E-4888
LH
1-1/8”
Eaton 1000839
12-15/16” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-4889
RH
Eaton 1000840
E-4740
LH
1-3/8”
Eaton 35455
13-7/16” E-2125
E-1887AHD
E-4741
RH
Eaton 35456
E-10911
LH
1-1/8”
Eaton 808068
13-15/32” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-10912
RH
Eaton 808069
E-3523
LH
1-3/8”
Eaton 1001580
14-1/4” E-2125
E-1887AHD
E-3524
RH
Eaton 1001581
E-9771
LH
1-1/8”
Eaton 807862
14-5/16” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-9772
RH
Eaton 807863
E-9055
LH
1-3/8”
Eaton 35430
15”
E-2125
E-1887AHD
E-9056
RH
Eaton 35431
E-10913
LH
1-1/8”
Eaton 808064
15-1/8” E-10897 (ES)
E-5481A (ES)
E-10244 Drive (ES II)
E-10760 Steer (ES II)
E-10914
RH
Eaton 808065
E-10915
LH
Eaton 811406
15-1/4” E-2125
E-1887AHD
E-10916
RH
Eaton 811407
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
