CAMSHAFTS
BRAKE CAMSHAFTS — DRIVE AXLE
FOR MERITOR DRIVE AXLES WITH 16-1/2” Q PLUS BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-11537
LH
1-3/16”
Meritor 2210U7485
10-13/64”
E-3993B E-2769HD
E-11536
RH
Meritor 2210V7484
E-9655
LH
1-3/16”
Meritor 2210Q9659
10-13/32”
E-3993B E-2769HD
E-9656
RH
Meritor 2210D7492
E-11541
LH
1-3/16”
Meritor 2210L7500
10-19/32”
E-3993B E-2769HD
E-11540
RH
Meritor 2210K7499
E-11543
LH
1-3/16”
Meritor 2210N7502
10-19/32”
E-3993B E-2769HD Induction hardened body.
E-11542
RH
Meritor 2210M7501
E-11545
LH
1-3/16”
Meritor 2210Q7843
10-45/64”
E-3993B E-2769HD
E-11544
RH
Meritor 2210P7842
E-11547
LH
1-3/16”
Meritor 2210W7511
10-13/16”
E-3993B E-2769HD
E-11546
RH
Meritor 2210V7510
E-9657
LH
1-3/16”
Meritor 2210A7515
10-15/16”
E-3993B E-2769HD
E-9658
RH
Meritor 2210Z7514
E-9659
LH
1-3/16”
Meritor 2210J7524
11-1/8”
E-3993B E-2769HD
E-9660
RH
Meritor 2210H7522
E-11619
LH
1-3/16”
Meritor 2210Z8216
11-13/64”
E-11904 E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11618
RH
Meritor 2210Y8215
E-9661
LH
1-3/16”
Meritor 2210A6943
11-9/16”
E-3993B E-2769HD
E-9662
RH
Meritor 2210Z6942
E-9663
LH
1-3/16”
Meritor 2210H5416
11-11/16”
E-3993B E-2769HD
E-9664
RH
Meritor 2210B7542
E-11623
LH
1-3/16”
Meritor 2210V8316
11-45/64”
E-11904 E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11622
RH
Meritor 2210U8315
E-11553
LH
1-3/16”
Meritor 2210G7547
11-13/16”
E-3993B E-2769HD
E-11552
RH
Meritor 2210F7546
E-9665
LH
1-3/16”
Meritor 2210L7552
11-15/16”
E-3993B E-2769HD
E-9666
RH
Meritor 2210K7551
E-11625
LH
1-3/16”
Meritor 2210T8288
11-61/64”
E-11904 E-2769HD
LX/MX 500 (1-5/8” Bushing
Journal)
E-11624
RH
Meritor 2210S8287
E-11555
LH
1-3/16”
Meritor 2210U7561
12-13/64”
E-3993B E-2769HD
E-11554
RH
Meritor 2210T7560
E-11557
LH
1-3/16”
Meritor 2210Y7565
12-5/16”
E-3993B E-2769HD
E-11556
RH
Meritor 2210X7564
E-9667
LH
1-3/16”
Meritor 2210C7569
12-7/16”
E-3993B E-2769HD
E-9668
RH
Meritor 2210B7568
E-11559
LH
1-3/16”
Meritor 2210S7845
12-29/64”
E-3993B E-2769HD Induction hardened body.
E-11558
RH
Meritor 2210R7844
Extended service camshafts CAN be used in place of standard camshafts.
Standard camshafts CANNOT be used in place of extended service camshafts when sing Extended service shoes and/or linings.
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
