BRAKE HARDWARE
BRAKE REPAIR KITS
E-3374HD MEGA PLUS CONVERT SPICER (DANA) 12-1/4” BRAKE FROM CAST TO FAB SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2414
Brake Shoe Anchor Pin Contains Euclids own design
anchor pin (E-2414) that allows
fabricated steel shoes to be used
with Std. Forge’s bolt-on Spider
for Cast Shoes. For use with old
style “Fast-Rise” Camshafts only.
Contains new Posi-Plus roller.
For use with the following Brake
Shoes: E-2393A (5-1/2”)
REPLACES:
Dayton/Batco 08107501
Dayton/Batco 081129
Haldex CQ67505
Dana/Spicer HK49125
Leland K288
Meritor R507075
2 2
E-2401
Anchor Pin Link
3 2
E-1107
Anchor Pin Jam Nut
4 2
E-2392
Anchor Pin Retainer
5 2
E-11741
Roller
6 1
E-2398
Return Spring
7 2
E-3007A
Roller Retainer
8 2
E-747
Spring Retainer
E-9282 MEGA PLUS CONVERT SPICER (DANA) 12-1/4” BRAKE FROM CAST TO FAB SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2414
Brake Shoe Anchor Pin Contains Euclid’s own design
anchor pin (E-2414) that allows
fabricated steel shoes to be used
with Std. Forge’s bolt-on Spider
for Cast Shoes. For use with New
Style Camshafts. For use with the
following Brake Shoes: E-2393A
(5-1/2”)
REPLACES:
Haldex CQ67506
Leland K338
Meritor R507089
2 2
E-2401
Anchor Pin Link
3 2
E-1107
Anchor Pin Jam Nut
4 2
E-2392
Anchor Pin Retainer
5 2
E-586
Roller
6 1
E-2398
Return Spring
7 2
E-539
Roller Retainer
8 2
E-747
Spring Retainer
E-2403HD MEGA PLUS CONVERT STD. FORGE 12-1/4” BRAKE FROM CAST TO FAB SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2414
Brake Shoe Anchor Pin Contains Euclids own design
anchor pin (E-2414) that allows
fabricated steel shoes to be used
with Std. Forges bolt-on Spider
for Cast Shoes. For use with the
following Brake Shoe:
E-2394 (7-1/2”)
REPLACES:
Dayton/Batco 081075
Dayton/Batco 08107500
Trailmobile 382403HD
Dana/Spicer 45A
Haldex CQ67503
Haldex CQ67503B
Dana/Spicer HK45XLS
Leland K50
Meritor R507068
2 2
E-2401
Anchor Pin Link
3 2
E-1107
Anchor Pin Jam Nut
4 2
E-2392
Anchor Pin Retainer
5 2
E-2395
Roller
6 2
E-2396
Roller Pin
7 2
E-527
Roller Pin Retainer
8 1
E-2398
Return Spring
9 2
E-2399
Retainer
