BRAKE HARDWARE
BRAKE REPAIR KITS
E-3484 MEGA PLUS MERITOR 12-1/4” “Q” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For use with the following Brake
Shoe: E-3491 (7-1/2”)
REPLACES:
Dayton/Batco 081093
Dayton/Batco 08109300
Trailmobile 383484
Dana/Spicer 44A
Haldex CQ67395
Dana/Spicer HK44XLS
Leland K154
Meritor KIT8004
Sirco LB3
Fruehauf MBCBK0024
Meritor R508004
2 2
E-1893
Anchor Pin Bushing
3 2
E-2767
Retainer Spring
4 1
E-3481A
Return Spring
5 2
E-3482
Roller Pin
6 2
E-3483
Roller
7 4
E-527
Roller Pin Retainer
8 2
E-747
Spring Retainer
E-10756 MEGA PLUS SPICER (DANA) 12-1/4” BRAKE WITH FABRICATED SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For use on Post 11/1/96 spiders
that use stepped anchor pins
(Spicer 7-1/2” Brake Shoe No.
M12WN127-X). This
12-1/4” brake utilizes many
components used on the standard
16-1/2” “Fast Change Brake. For
use with “0794” Camshafts only.
REPLACES:
Dayton/Batco 08104900
Dayton/Batco 08114900
Haldex CQ67437
Leland K373
Sirco LB10
Meritor R507092
2 2
E-586
Roller
3 2
E-1893S
Anchor Pin Bushing
4 2
E-2767
Retainer Spring
5 1
E-2398
Return Spring
6 2
E-747
Spring Retainer
7 2
E-539
Roller Retainer
E-14539 MEGA PLUS SPICER (DANA) 12-1/4” BRAKE WITH FABRICATED SHOES FOR ABS
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
NSS*
Anchor Pin
For use on on Pre 11/1/96 and
Post 11/1/12 brakes. This
12-1/4” brake utilizes many
components used on the standard
16-1/2” “Fast Change Brake. For
use with “0794” Camshafts only.
REPLACES:
Bendix/Spicer HK49-150
Haldex CQ67437
Meritory R507017
2 2
E-586
Roller
3 2
NSS*
Roller Retainer
4 2
E-14657
Retainer Spring
5 1
NSS*
Return Spring
6 4
E-2392
Spring Retainer
7 2
E-2766S
Pin
8 2
E-1893S
Bushing
9 2
E-747
Retainer
10 4
E-2391
Washer
*Not Sold Separately
