BRAKE HARDWARE
BRAKE REPAIR KITS
E-10867 MEGA PLUS MERITOR COACH 14-1/2” “W” SERIES BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 1
E-10826
Return Spring
For use with the following Meritor
Coach 14-1/2” x 8” “W” Series
Brake Shoe, Type 1: E-10805 (8”)
REPLACES:
2 2
E-10828
Anchor Pin Bushing
3 2
E-4961A
3/4”-16 Lock Nut
4 2
E-10823
Roller
5 2
E-10831
Anchor Pin Washer
6 2
E-10832
Anchor Pin Washer
E-10869 MEGA PLUS MERITOR COACH 14-1/2” “W” SERIES BRAKE DRIVE AXLE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-10828
Anchor Pin Bushing For use with the following Meritor
Coach 14-1/2” x 10” “W” Series
Brake Shoe, Type 1 and Type 3:
E-10810 (10”)
REPLACES:
2 2
E-4961A
3/4”-16 Lock Nut
3 1
E-10826
Return Spring
4 2
E-10824
Roller
5 2
E-5095
Camshaft Spacer
Washer
6 2
E-10833
Anchor Pin Washer
7 2
E-10865
Lock Washer
E-10870 MEGA PLUS MERITOR COACH 14-1/2” “W” SERIES BRAKE DRIVE AXLE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 1
E-10826
Return Spring
For use with the following Meritor
Coach 14-1/2” x 10” “ W” Series
Brake Shoe, Type 2: E-10809 (10”)
REPLACES:
Dayton/Batco 08125300
Sirco BK145R
Meritor KIT6003
2 4
E-10834
Anchor Pin Lock Ring
3 2
E-10836
Anchor Pin Bushing
4 2
E-10838
Roller
5 2
E-10835
Anchor Pin
6 2
NSS*
Bolt
E-10841-A MEGA PLUS MERITOR COACH 14-1/2” “W” SERIES BRAKE STEER AXLE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-10818
Return Spring
For use with the following Meritor
Coach 14-1/2” x 4” and 6” “W”
Series Brake Shoes: E-10802 (4”),
E-10803 (6”)
2 2
E-10814
Anchor Pin
3 2
NSS*
Lock Bolt
4 1
E-10817
Anchor Pin Lock
5 2
E-10812
Roller
6 4
E-801
Lock Ring
7 2
NSS*
Washer
*Not Sold Separately
