78 / 561
U.S. 888-725-9355
MeritorPartsOnline.com
1-73
Canada 800-387-3889
BRAKE HARDWARE
BRAKE REPAIR KITS
E-10875 MEGA PLUS DEXTER 12-1/4” “PQ” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For use with the following Dexter
12-1/4” “PQ” Brake Shoes:
E-10876, E-10877, E-10878
REPLACES:
Dayton/Batco 08104700
Dana/Spicer HK47XLS-150
Leland K353
Leland K369
Sirco LB3D
Meritor R507095
2 2
E-1893
Anchor Pin Bushing
3 2
E-2767
Retainer Spring
4 1
E-2398
Return Spring
5 2
E-2396
Roller Pin
6 2
E-2395
Roller
7 4
E-527
Roller Pin Retainer
8 2
E-747
Spring Retainer
E-2126 MEGA PLUS EATON 12-1/4” SINGLE ANCHOR PIN BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 1
E-1403
Anchor Pin
For use with the following Brake
Shoe: E-1398 (7-1/2”)
REPLACES:
Dayton/Batco 081076
Dayton/Batco 08107600
Trailmobile 382126
Dana/Spicer 40A
Haldex CQ67388
Dana/Spicer HK40
Leland K106
Leland L1209
Sirco LB4
Meritor R507000
Dana/Spicer TA40A
2 2
E-580
Camshaft Spacer
Washer
3 1
E-526
Camshaft Lock Ring
4 2
E-1406
Roller
5 1
E-937
Locknut
6 1
E-1402
Return Spring
7 2
E-1400
Return Spring
8 1
E-3975
Lock Washer
E-2286 MEGA PLUS FRUEHAUF “PROPAR” 12-1/4” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-609
Anchor Pin
For use with the following Brake
Shoe: E-1580 (8”)
REPLACES:
Dayton/Batco 081077
Dayton/Batco 08107700
Trailmobile 382286
Dana/Spicer 41A
Haldex CQ67394
Leland K105
Sirco LB5
Fruehauf MBCBK0015
Meritor R507005
Dana/Spicer TA41A
2 2
NSS*
Roll Pin
3 2
E-920
Anchor Pin Bushing
4 2
E-747
Spring Retainer
5 2
E-1581
Retainer
6 2
E-1582
Roller
7 1
E-1583
Return Spring
*Not Sold Separately
