BRAKE HARDWARE
BRAKE REPAIR KITS
E-2030HD MEGA PLUS SPICER (DANA) and STD. FORGE 12-1/4” BRAKE WITH CAST SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2029
Anchor Pin
For use with the following Brake
Shoes: E-1412A (5-1/2”), E-1413A
(7-1/2”)
REPLACES:
Dayton/Batco 081073
Dayton/Batco 08107300
Dayton/Batco 081422
Trailmobile 21K62
Trailmobile 382030HD
Dana/Spicer 42A
Haldex CQ67397
Dana/Spicer HK45XLS
Dana/Spicer M10LK105X
Meritor R507014
Dana/Spicer TA42A
2 1
NSS*
Anchor Pin Link
3 2
E-10776
Anchor Pin Lock Ring
4 2
E-1107
Anchor Pin Jam Nut
5 2
E-2101
Return Spring
6 2
E-1808
Brake Shoe Bushing
7 2
E-2176
Roller
8 2
E-501
Roller Pin
9 2
E-773
Roller Pin Set Screw
10 2
E-1106
Anchor Pin Lock Washer
E-2402HD MEGA PLUS STANDARD FORGE 12-1/4” BRAKE WITH FABRICATED SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2390
Anchor Pin
For use with the following Brake
Shoes: E-9025 (4”), E-9026 (5”),
E-2393
(5-1/2”), E-2394 (7-1/2”)
REPLACES:
Dayton/Batco 081074
Dayton/Batco 08107400
Eaton 125766
Trailmobile 382402HD
Dana/Spicer 43A
Eaton 5-2244
Eaton 52244B
Haldex CQ67398
Dana/Spicer HK43XLS
Leland K352
Leland K69
Sirco LB1
Dana/Spicer M12LK101X
Meritor R507015
2 4
E-2391
Anchor Pin Washer
3 4
E-2392
Anchor Pin Retainer
4 2
E-2395
Roller
5 2
E-2396
Roller Pin
6 2
E-527
Roller Pin Retainer
7 1
E-2398
Return Spring
8 2
E-2399
Retainer
9 2
E-2389
Anchor Pin Bushing
10 2
E-1106
Anchor Pin Lock Washer
E-1812 MEGA PLUS STD. FORGE 12-1/4” BRAKE WITH FLAT HEAD CAMSHAFTS
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-1813
Brake Shoe Anchor Pin For old style cast brake with flat
head camshafts. Cannot change to
“S” cam. Shoe no longer available.
REPLACES:
Dayton/Batco 081072
Meritor R507067
2 1
NSS*
Anchor Pin Link
3 2
E-1106
Anchor Pin Lock Washer
4 2
E-1107
Anchor Pin Jam Nut
5 2
E-1025
Return Spring
6 2
E-1808
Brake Shoe Bushing
7 2
E-947
Brake Shoe Wear Plate
8 2
NSS*
Screw
*Not Sold Separately
