Assembly PN
Description
Drum PN
3.34
4.8
7.05
19.52
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.44
6.50
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 6-spoke 22"
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
76227 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
87 lbs.
001-76227
6-Spoke x 22" 16.5 x 7" Brake Drum
52230-10
16.50
8.39
9.44
7.50
N/A
9.95
192
N/A
N/A
PRT-00143
Option "T" - ABS Tone Ring
6.77
PRT-13237
100-Tooth Tone Ring - Powdered Metal
Part Number
Description
Pitch Diameter
Notes
Rim Size 20 x 8.0 max
Uses PRT-00075 Rim Nuts
Uses PRT-00123 Rim Clamps
Uses PRT-00114 Rim Stud
Uses PRT-00152 Drum Bolt Nut
