24 / 105
23
Copyright © 2015 KIC LLC
Assembly PN
Description
Drum PN
3.34
4.87
6.97
12.50
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
0.45
6.39
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 3-spoke 15"
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
7000 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
97 lbs.
001-70003
3-Spoke x 15" Wheel, 12.25 x 7.5" Drum
52743-11
12.25
8.88
8.50
7.89
N/A
10.71
163
N/A
N/A
PRT-00143
Option "T" - ABS Tone Ring
6.77
PRT-00981
80-Tooth Tone Ring
Part Number
Description
Pitch Diameter
Notes
Rim Size 15 x 8.0 max
