3.34
5.04
7.22
11.25
6 Holes 5/16"-18 UNC,
5.50 Bolt Circle
1.14
6.50
SAE "N" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
2540 Series Assemblies
HM218210 / HM218248
HM212011 / HM212049
Std. Hub Weight
55 lbs.
001-02540
Hub Pilot, M22 x 3.70 Stud, 16.5 x 6" Drum Bal
54242-018
16.50 6.47
8.78
9.76
M22 x 1.5
2.13
4.74
182
5.02
PRT-00121
001-02540L
Hub Pilot, M22 x 3.97 Stud, 16.5 x 6" Drum Bal
54242-018
16.50 6.47
8.78
9.76
M22 x 1.5
2.36
4.74
183
5.02
PRT-00117
001-02540X
Hub Pilot, M22 x 4.25 Stud, 16.5 x 6" Drum Bal
54242-018
16.50 6.47
8.78
9.76
M22 x 1.5
2.65
4.74
183
5.02
PRT-00122
001-02544L
Hub Pilot, M22 x 3.97 Stud, 16.5 x 6" Drum Bal
54224-018
15.00 4.77
8.78
8.86
M22 x 1.5
2.48
3.96
126
4.90
PRT-00117
001-02545
Hub Pilot, M22 x 3.70 Stud, 16.5 x 5" Drum Bal
54238-018
16.50 5.29
8.78
9.14
M22 x 1.5
2.12
4.25
158
4.88
PRT-00121
001-02545L
Hub Pilot, M22 x 3.97 Stud, 16.5 x 5" Drum Bal
54238-018
16.50 5.29
8.78
9.14
M22 x 1.5
2.36
4.25
159
4.88
PRT-00117
001-02546
Hub Pilot, M22 x 3.70 Stud, 15 x 6" Drum Bal
54295-018
15.00 6.64
8.78
9.85
M22 x 1.5
2.12
4.96
134
4.89
PRT-00121
001-02546L
Hub Pilot, M22 x 3.97 Stud, 15 x 6" Drum Bal
54295-018
15.00 6.64
8.78
9.85
M22 x 1.5
2.36
4.96
135
4.89
PRT-00117
001-02546X
Hub Pilot, M22 x 4.25 Stud, 15 x 6" Drum Bal
54295-018
15.00 6.64
8.78
9.85
M22 x 1.5
2.65
4.96
137
4.89
PRT-00122
001-02547
Hub Pilot, M22 x 3.70 Stud, 16.5 x 7" Drum Bal
60001-018
16.50 7.56
8.78 10.62
M22 x 1.5
2.23
5.70
167
4.92
PRT-00121
001-02547L
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum Bal
60001-018
16.50 7.56
8.78 10.62
M22 x 1.5
2.47
5.70
169
4.92
PRT-00117
