Assembly PN
Description
Drum PN
3.37
4.43
6.30
11.25
6 holes 5/16"-18 UNC.
4.50 Bolt Circle
0.67
5.52
SAE "FF/FG" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
137 Series Assemblies
HM212011 / HM212049
3720 / 3782
Std. Hub Weight
45 lbs.
002-00137
Hub Pilot, M22 x 3.70 Stud, 15 x 4" Drum Bal
54224-018
15.00 4.77
8.78
8.86
M22 x 1.5
2.36
3.17
115
5.69
PRT-00121
002-00137L
Hub Pilot, M22 x 3.97 Stud, 15 x 4" Drum Bal
54224-018
15.00 4.77
8.78
8.86
M22 x 1.5
2.61
3.17
118
5.69
PRT-00117
002-00138
Stud Pilot, 3/4-16 RH Stud, 15 x 4" Drum Bal
54224-018
15.00 4.77
8.78
8.86
3/4-16 RH
1.78
3.17
113
5.69
PRT-01294
RH
002-00139
Stud Pilot, 3/4-16 LH Stud, 15 x 4" Drum Bal
54224-018
15.00 4.77
8.78
8.86
3/4-16 LH
1.78
3.17
113
5.69
PRT-01295
LH
002-00142
Hub Pilot, M22 x 3.70 Stud, 16.5 x 5" Drum Bal
54238-018
16.50 5.29
8.78
9.14
M22 x 1.5
2.38
3.45
148
5.69
PRT-00121
002-00142L
Hub Pilot, M22 x 3.97 Stud, 16.5 x 5" Drum Bal
54238-018
16.50 5.29
8.78
9.14
M22 x 1.5
2.62
3.45
149
5.69
PRT-00117
002-00144
Hub Pilot, M22 x 3.70 Stud, 15 x 5" Drum Bal
54282-018
15.00 6.26
8.78
9.47
M22 x 1.5
2.36
3.17
122
5.69
PRT-00121
002-00144L
Hub Pilot, M22 x 3.97 Stud, 15 x 5" Drum Bal
54282-018
15.00 6.26
8.78
9.47
M22 x 1.5
2.36
3.17
123
5.69
PRT-00117
Option "T" - ABS Tone Ring
6.46
PRT-00925
100-Tooth Tone Ring
Part Number
Description
Pitch Diameter
