Assembly PN
Description
Drum PN
4.50
6.94
9.06
11.25
6.25 X 8 TPI Threaded
0.44
6.50
SAE "P" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Outboard drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
40130 Series Assemblies
HM518410 / HM518445
HM518410 / HM518445
Std. Hub Weight
64 lbs.
004-00130
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
M22 x 1.5
2.63
8.80
172
1.82
PRT-00117
004-00130L
Hub Pilot, M22 x 4.82 Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
M22 x 1.5
3.50
8.80
174
1.82
PRT-00118
004-00131
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
3/4-16 RH
1.57
8.80
169
1.82
PRT-01292
RH
004-00132
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7" Drum
60001-01
16.50 7.56
8.78 10.62
3/4-16 LH
1.63
8.80
169
1.82
PRT-01293
LH
Option "T" - ABS Tone Ring
6.77
PRT-13237
100-Tooth Tone Ring - Powdered Metal
Part Number
Description
Pitch Diameter
