Assembly PN
Description
Drum PN
4.06
5.95
8.47
11.25
6 Holes 5/16"-18 UNC.,
6.75 Bolt Circle
N/A
N/A
SAE "K30" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 11.25" Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
2134 Series Assemblies
752 / 759
742 / 740
Std. Hub Weight
23 lbs.
006-02134
Hub Pilot, M22 x 3.97 Stud, 16.5 x 7" Drum Bal
54261-018
16.50 7.60
8.78 10.59
M22 x 1.5
2.65
8.99
148
1.60
PRT-00117
006-02134L
Hub Pilot, M22 x 4.82" Stud, 16.5 x 7" Drum Bal
54261-018
16.50 7.60
8.78 10.59
M22 x 1.5
3.50
8.99
150
1.60
PRT-00118
006-02136
Stud Pilot, 3/4-16 RH Stud, 16.5 x 7" Drum Bal
54261-018
16.50 7.60
8.78 10.59
3/4-16 RH
1.58
8.99
148
1.60
PRT-01292
RH
006-02137
Stud Pilot, 3/4-16 LH Stud, 16.5 x 7" Drum Bal
54261-018
16.50 7.60
8.78 10.59
3/4-16 LH
1.64
8.99
148
1.60
PRT-01293
LH
006-02138
Hub Pilot, M22 x 3.97 Stud, 16.5 x 8-5/8" Drum Bal
54229-018
16.50 9.00
8.78 11.39
M22 x 1.5
2.57
9.7
182
1.71
PRT-00117
006-02138L
Hub Pilot, M22 x 4.82" Stud, 16.5 x 8-5/8" Drum Bal
54229-018
16.50 9.00
8.78 11.39
M22 x 1.5
3.42
9.7
183
1.71
PRT-00118
Option "T" - ABS Tone Ring
7.28
PRT-13301
100-Tooth Tone Ring
Part Number
Description
Pitch Diameter
Notes
Fill port option available.
