STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 3
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
www.stemcokaiser.com
CHEVROLET
3 1/2 Ton - D90, F90,
H90, J90, M90, T90, W90
12000#(F-120D)
1975 to date
8885621
B 1.745 x 9.37
K121G
70.121.07 50.121.07
18000#(FL-901)
1970 to date
2452865
B 1.999 x 10.90
KH901L
78.901.12 58.901.12
16000#(FL-931)
1973-1978
2036352
B 1.999 x 11.21
KH931L
78.931.12 58.931.12 ST70-12
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
CHEVROLET, CLARK,
DODGE, EAGLE,
EATON, FORD
continued
CLARK
(Industrial Axles)
F-553 Air Start/Gen. Carts
A 1.234 x 7.62
K98I
70.098.09 50.098.09
DODGE
1 1/2 Ton - D400, M400,
P400, S400
5000#
1960-1973
2275521
1752310
C 1.124 x 7.25
K50D
70.050.04 50.050.04
5000#
1973-1978
2275521
C 1.124 x 7.25
K50D
70.050.04 50.050.04
2 Ton - C500, D500,
M500, R500, S500,
PC500, PD500
5000#
1957-1972
2275521
C 1.124 x 7.25
K50D
70.050.04 50.050.04
7000#
1957-1973
1843208
B 1.234 x 7.43
K70D
70.070.04 50.070.04
5000#
1974 to date
2275521
C 1.124 x 7.25
K50D
70.050.04 50.050.04
2 1/2 Ton - C600, D600,
L600, S600, PC600,
PD600, C700, CT700,
D700, L700, S700
5000#
1957-1971
2275521
1752310
C 1.124 x 7.25
K50D
70.050.04 50.050.04
7000#
1957-1973
1843208
B 1.234 x 7.43
K70D
70.070.04 50.070.04
5000#
1960-1973
2275521
C 1.124 x 7.25
K50D
70.050.04 50.050.04
7000#
1960-1973
1843208
B 1.234 x 7.43
K70D
70.070.04 50.070.04
7000#
1974 to date
3780539
A 1.234 x 7.64
K75D
9000#
1960-1973
1818726
B 1.433 x 8.50
KD901R
74.901.18 54.901.18 ST70-9
11000#
1960-1968
1643174
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#
1969-1971
2808618
B 1.794 x 9.12
K901L
70.901.12 50.901.12 ST70-7
3 Ton - C800, CN800,
CNT800, D800, NCT800,
C850
7000#
1960-1973
1843208
B 1.234 x 7.43
K70D
70.070.04 50.070.04
9000#
1960 to date
1818726
B 1.433 x 8.50
KD901R
74.901.18 54.901.18 ST70-9
11000#
1960-1968
1643174
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#
1969-1977
2808618
B 1.794 x 9.12
K901L
70.901.12 50.901.12 ST70-7
4 Ton - C900, CN900,
CT900, CNT900, NC900,
NCT900, VL900, VLT900
7000#
1960-1973
1843208
B 1.234 x 7.43
K70D
70.070.04 50.070.04
9000#
1960 to date
1818726
B 1.433 x 8.50
KD901R
74.901.18 54.901.18 ST70-9
11000#
1960-1968
1643174
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#
1969-1973
2808618
B 1.794 x 9.12
K901L
70.901.12 50.901.12 ST70-7
16000#
1974 to date
B 1.999 x 11.04
KH901L
78.901.12 58.901.12
5 Ton - C1000, CT1000,
DN1000, DNT1000,
LN1000, LNT1000
7000#
1970-1973
1843208
B 1.234 x 7.43
K70D
70.070.04 50.070.04
9000#
1960 to date
1818726
B 1.433 x 8.50
KD901R
74.901.18 54.901.18 ST70-9
11000#
1960-1968
1643174
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000#
1969-1973
2808618
B 1.794 x 9.12
K901L
70.901.12 50.901.12 ST70-7
16000#
1974 to date
B 1.999 x 11.04
KH901L
78.901.12 58.901.12
EAGLE
05
12000#
123
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
EATON
(See Spicer / Dana / Eaton)
FORD
E100, E250, E350
1975 to date
D5UZ-3111B
D5UZ-3111D
E0TZ-3111A
A 1.054 x 6.68
KE350F
75.350.06 55.350.06 ST70-15
