8 / 69
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
www.stemcokaiser.com
FORD
2 1/2 Ton - B700, C700,
F700, LN700, N700,
T700, B750, C750, F750,
LN750, N750, T750
7000#
Air Brakes
1989-2003
E9HZ-3111C
B 1.43 x 8.25
K76F
6
70.076.06
6
50.076.06
6
ST70-17
7000-9000#
Air Brakes
After Series
No. 40001
1975-1988
D6TZ-3111A
B 1.43 x 8.25
K75F
5
70.075.06
5
50.075.06
5
ST70-17
9000#
Hydraulic Brakes
1960-1983
D1HZ-3111A
C2TZ-3111G
B 1.433 x 8.50
KD901R
74.901.18 54.901.18 ST70-9
9000#
Air Brakes
1975-1988
D6HZ-3111B
D6HZ-3111D
B 1.606 x 9.07
K95F
5
70.095.06
5
50.095.06
5
ST70-13
9000#
Air Brakes
1989 to date
E9HZ-3111B
B 1.606 x 9.07
K96F
6
70.096.06
6
50.096.06
6
ST70-13
C.P.S. 11000#
1960-1973
D0HZ-3111C
B 1.606 x 8.81
K970R
70.970.18 50.970.18 ST70-13
C.P.S. 12000#
1960-1973
D0HZ-3111C
B 1.606 x 8.81
K970R
70.970.18 50.970.18 ST70-13
12000#
Conventional
1960-1969
C3TZ-3111B
D1HZ-3111B
B 1.794 x 9.12
K901L
70.901.12 50.901.12 ST70-7
14600#
1995-1998
F5HZ-3111A
A 1.810 x 10.54
K146F
ST70-33
800-850-880 Series
C800, CT800, C850,
CT850, N850, NT850,
N8000, F, L, LN, LNT, LT,
LTS, T800, F, T850 &
LNT, LT800, F880, LT880,
LNT880
6000#
1970-1988
C7TZ-3111A
A 1.230 x 8.90
K70F
4
70.073.06 50.073.06
7000#
1957-1969
B7TZ-3111B
C2TZ-3111B
B 1.234 x 7.43
K70D
70.070.04 50.070.04
7000#
Hydraulic Brakes
1970-1988
C7TZ-3111A
A 1.230 x 8.90
K70F
4
70.073.06 50.073.06
7000-9000#
Air Brakes
After Series
No. 40, 001
1975-1988
D6TZ-3111A
B 1.43 x 8.25
K75F
5
70.075.06
5
50.075.06
5
ST70-17
7000#
Air Brakes
1989 to date
E9HZ-3111C
B 1.43 x 8.25
K76F
6
70.076.06
6
50.076.06
6
ST70-17
9000#
Hydraulic Brakes
1957-1983
D1HZ-3111A
C2TZ-3111G
B 1.433 x 8.50
KD901R
74.901.18 54.901.18 ST70-9
9000#
Air Brakes
1975-1988
D6HZ-3111B
D6HZ-3111D
B 1.606 x 9.07
K95F
5
70.095.06
5
50.095.06
5
ST70-13
9000#
Air Brakes
1989 to date
E9HZ-3111B
B 1.606 x 9.07
K96F
6
70.096.06
6
50.096.06
6
ST70-13
11000#
Conventional
1957-1963
B7TZ-3111C
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
C.P.S. 11000#
1964-1970
D0HZ-3111C
B 1.606 x 8.81
K970R
70.970.18 50.970.18 ST70-13
12000#
Conventional
1960-1988
C3TZ-3111B
D1HZ-3111B
B 1.794 x 9.12
K901L
70.901.12 50.901.12 ST70-7
C.P.S. 12000#
Hydraulic Brakes
1960-1970
D0HZ-3111C
B 1.606 x 8.81
K970R
70.970.18 50.970.18 ST70-13
12000#
Conventional
1975-1988
D6HZ-3111A
B 1.794 x 10.07
K941F
5
70.941.06
5
50.941.06
5
ST70-7
12000#
Conventional
1989 to date
B 1.794 x 10.07
K942F
6
70.942.06
6
50.942.06
6
ST70-7
FORD
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 5
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
continued
