Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
www.stemcokaiser.com
FORD
800-850-880 Series
C800, CT800, C850,
CT850, N850, NT850,
N8000, F, L, LN, LNT, LT,
LTS, T800, F, T850 &
LNT, LT800, F880, LT880,
LNT880
18000#
Hydraulic Brakes
1960-1974
D0HZ-3111E
B 1.999 x 11.04
KH901L
78.901.12 58.901.12
18000#
Air Brakes
1975 to date
D5HZ-3111C
B 1.999 x 11.21
KH931L
78.931.12 58.931.12 ST70-12
20000#
1970-1974
D0HZ-3111E
B 1.999 x 11.04
KH901L
78.901.12 58.901.12
20000#
1975 to date
D5HZ-3111C
B 1.999 x 11.21
KH931L
78.931.12 58.931.12 ST70-12
FORD,
FREIGHTLINER,
FWD, GMC
FREIGHTLINER
(See Rockwell, Spicer/Dana/Eaton)
FWD
(See Rockwell, Spicer/Dana/Eaton Axles)
GMC
1500 Series - P1500
1960-1965
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
G1500
1966-1967
3854744
A 1.109 x 6.34
K51G
70.051.07 50.051.07
2500 Series - P2500
1960-1965
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
1966-1967
3854744
A 1.109 x 6.34
K51G
70.051.07 50.051.07
C3500 - Heavy Duty
Pickup
1991-
15665666
A 1.179 x 6.35
K56G
70.056.07 50.056.07 ST70-4
3500 Series -
Conventional
5000# (F-050)
1963-1966
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
P3500 -
Single Rear Wheels
5000# (F-050)
1965-1967
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
5000#
1986 to date
15522020
A 1.179 x 6.35
K56G
70.056.07 50.056.07 ST70-4
Dual Rear Wheels
5000# (F-050)
1965-1967
3854744
A 1.109 x 6.34
K51G
70.051.07 50.051.07
5000#
1986 to date
15522020
88911968
88911987
A 1.179 x 6.35
K56G
70.056.07 50.056.07 ST70-4
4000 Series
5000#
(F-050, F-055)
1963-1966
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
7000# (F-070)
1963-1966
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
4500 Series
5000# (F-055)
1967-1970
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
5000 Series - B5000,
DW5000, W5000
5000# (F-050)
1967-1972
3854744
A 1.109 x 6.34
K51G
70.051.07 50.051.07
All other 5000 Series
5000#
(F-050, F-055)
1967-1970
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
7000# (F-070)
1963-1966
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
All other-5500 Series
5000# (F-050)
1966-1970
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
5000# (F-050)
1966-1972
3854744
A 1.109 x 6.34
K51G
70.051.07
50.051.07
5000# (F-055)
1975-1990
722166
A 1.179 x 6.35
K55G
70.055.07 50.055.07 ST70-4
7000# (F-070)
1963 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
9000# (F-090)
1970 to date
2321013
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
KODIAK - C “Series”
7000# (FM7)
88936119
B 1.499 x 7.15
K70R
70.070.18 50.070.18 ST70-28
8000# (FM8)
88936011
B 1.499 x 7.50
K80R
70.080.18 50.080.18 ST70-28
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 7
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
