Steering Knuckle King Pin Kit
revision date 11/2012
SPICER / DANA / EATON,
STERLING, VOLVO,
WATSON / CHALIN
SPICER / DANA / EATON
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
I CODES
12000# I-120
For code 02309
586806C91
B 1.609 x 9.16
K310I
70.310.09 50.310.09 ST70-5
12000# I-120S
I-120SG,
I-120SGL
1989 to date
1668411C91
120KK100
B 1.921 x 9.87
K120I
8
70.120.09
8
70.120.99
3, 8
50.120.09
8
ST70-19
13200# I-132
588808C91
1658394C91
B 1.609 x 9.66
K140I
70.140.09 50.140.09 ST70-5
14000# I-140S
I-140SG, I-140W
I-132SG
1990 to date
140KK100
329022
B 2.046 x 10.12
K141S
8
70.141.19
8
50.141.19
8
ST70-24
14600#
I-146S I-146SA
120KK102
B 1.860 x 10.75
K146S
16000# I-160S,
I-160W
18000# I-180S,
I-180W
20000# I-200S,
I-200W
22000# I-220S,
I-220W
220KK100
1685405C91
329023
B 2.046 x 11.00
K160S
70.160.19 50.160.19 ST70-24
16000# I-160S,
I-160SB
for MCI Buses
only
161KK100
B 2.046 x 11.00
K161S
ST70-24
I-161
329116
B 1.794 x 11.00
K162S
ST70-7
VOLVO
STERLING
(See Rockwell, Spicer/Dana/Eaton Axles)
9000# FM9
85108338
E 2.441 x 8.92
K536M
12000# FM12
85108338
E 2.441 x 8.92
K536M
10000# VF10
12000# VF12
12500# VF125
FAX5.5
FAX5.7
3130711
V3090267
E 1.777 x 8.62
K122V
9
VF14, VF16, VF18
3090266
E 1.969 x 9.88
K140V
3093704
B 1.794 x 8.87
K981R
70.981.18 50.981.18 ST70-7
V1112810
A 1.625 x 9.19
K120E
70.120.05 50.120.05 ST70-6
85106184
A 1.794 x 9.05
K122E
K125E
13
70.122.05
70.125.05
13
50.122.05 ST70-7
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 20
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
continued
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
WATSON / CHALIN
1100 Series
SRK102
B 1.794 x 10.40
K961L
70.961.12 50.961.12 ST70-7
SRK105
B 1.999 x 11.22
KH931L
78.931.12 58.931.12 ST70-12
SRK103
B 1.500 x 8.93
K941R
70.941.18 50.941.18 ST70-28
SL2089, SL2090,
SLTL2095,
STL2096
SRK120
B 1.999 x 11.21
K181R
ST70-12
