STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
King Pin Dimensions Interchange
revision date 11/2012
page 22
Dia. Length Type Make Qwik Kit
TM
Plus Kit
TM
Econo Kit
TM
Dia. Length Type Make Qwik Kit
TM
Plus Kit
TM
Econo Kit
TM
Dia. Length Type Make Qwik Kit
TM
Plus Kit
TM
Econo Kit
TM
1.500 8.930 B ROCKWELL K941R 70.941.18 50.941.18
1.606 8.812 B ROCKWELL K970R 70.970.18 50.970.18
1.606 9.080 B FORD K95F 70.095.06 50.095.06
1.606 9.080 B FORD K96F 70.096.06 50.096.06
1.608 9.578 B
IH K119I
70.119.09 50.119.09
1.609 9.160 A
IH K309I
70.309.09 50.309.09
1.609 9.160 B
IH K310I
70.310.09 50.310.09
1.609 9.380 B ROCKWELL K971R 70.971.18 50.971.18
1.609 9.660 A
IH K139I
70.139.09 50.139.09
1.609 9.660 B
IH K140I
70.140.09 50.140.09
1.609 9.750 E CHEVY K125G 70.125.07 50.125.07
1.614 8.000 G CHEVY K80G NA
NA
1.625 7.468 F MACK K533M 70.533.13 50.533.13
1.625 9.190 A EATON K120E 70.120.05 50.120.05
1.625 9.190 A EATON K121E 70.121.05 50.121,05
1.745 9.380 B CHEVY K121G 70.121.07 50.121.07
1.771 8.060 B ALLIANCE K80A NA
NA
1.771 9.230 B ALLIANCE K120A NA
NA
1.777 8.620 E VOLVO K122V NA
NA
1.794 8.870 B ROCKWELL K981R 70.981.18 50.981.18
1.794 9.050 A DANA K125E 70.125.05 NA
1.794 9.050 A EATON K122E 70.122.05 50.122.05
1.794 9.050 A LINK K123K NA
NA
1.794 9.050 A LINK K132K NA
NA
1.794 9.180 B ROCKWELL K901L 70.901.12 50.901.12
1.794 9.190 B ROCKWELL KH946R 78.946.18 58.946.18
1.794 9.220 E GMC COACH K175G NA
NA
1.794 9.970 C DANA K123E 70.123.05 50.123.05
1.794 10.070 B FORD K941F 70.941.06 50.941.06
1.794 10.070 B FORD K942F 70.942.06 50.942.06
1.794 10.392 B ROCKWELL K120R 70.120.18 50.120.18
1.794 10.400 B ROCKWELL K931L 70.931.12 50.931.12
1.794 10.400 B ROCKWELL K961L 70.961.12 50.961.12
1.794 10.400 B ROCKWELL KG931R 77.931.18 57.931.18
1.794 10.410 B ROCKWELL K921L 70.921.12 50.921.12
1.794 10.687 E GMC COACH K170G NA
NA
1.794 11.000 B NEOPLAN K162S NA
NA
1.810 9.540 H HENDRICKSON K120H NA
NA
1.810 10.530 B FORD K146F NA
NA
1.810 10.560 A WESTPORT K125W 70.125.23 70.125.23
1.810 10.560 A WESTPORT K126W 70.126.23 50.126.13
1.810 10.560 A WESTPORT K127W 70.127.23 50.127.23
1.810 10.781 A WESTPORT K120W NA
NA
1.860 10.750 B SPICER K146S NA
NA
1.872 9.050 C DANA K147E 70.147.05 70.147.05
1.872 9.050 C DANA K148E NA
NA
1.872 9.050 A EATON K146E 70.146.05 50.146.05
1.872 9.970 A EATON K180E 70.180.05 50.180.05
1.889 9.200 G CHEVY K110G NA
NA
1.889 9.620 G CHEVY K120G NA
NA
1.921 9.875 B
IH K120I
70.120.09 50.120.09
1.921 10.625 B
IH K120I
70.120.09 50.120.09
1.969 8.770 J
MAN K120N NA
NA
1.969 8.880 E VOLVO K140V NA
NA
1.999 11.040 B ROCKWELL KH901L 78.901.12 58.901.12
1.999 11.212 B ROCKWELL K180R 70.180.18 50.180.19
1.999 11.212 B ROCKWELL K181R NA
NA
1.999 11.220 B ROCKWELL KH931L 78.931.12 58.931.12
1.999 11.320 A KGI
K150KG NA
NA
2.046 10.070 B DANA K200S NA
NA
2.046 10.070 C DANA K201S NA
NA
2.046 10.120 B IH / SPICER K141S 70.141.19 50.141.19
2.046 11.000 B DANA K161S NA
NA
2.046 11.000 B SPICER K160S 70.160.19 50.160.19
2.125 8.750 F MACK K616M 70.616.13 50.616.13
2.125 9.750 B ALLIANCE K160A NA
NA
2.248 11.300 B IMT K700T NA
NA
2.441 8.920 E MACK K536M NA
NA
0.922 7.000 A FORD K40F 70.040.06 50.040.06
1.054 6.690 A FORD KE350F 75.350.06 55.350.06
1.101 7.100 A MITSUBISHI K60U NA
NA
1.109 6.340 A CHEVY K51G 70.051.07 50.051.07
1.124 7.125 C DODGE K50D 70.050.04 50.050.04
1.179 6.360 A CHEVY K55G 70.055.07 50.055.07
1.179 6.360 A CHEVY K56G 70.056.07 50.056.07
1.179 6.360 A WORKHORSE K58G 70.058.07 NA
1.179 7.310 A WORKHORSE K50W NA
NA
1.181 7.380 A ISUZU K68Z NA
NA
1.181 7.380 A ISUZU K69Z NA
NA
1.230 8.906 A FORD K70F 70.073.06 50.073.06
1.231 7.859 A FORD K50F 70.053.06 50.053.06
1.233 7.437 A FORD K60F NA
NA
1.234 6.780 A MERITOR K60R NA
NA
1.234 7.437 B DODGE K70D 70.070.04 50.070.04
1.234 7.660 A
IH K98I
70.098.09 50.098.09
1.249 7.875 A CHEVY K70G 70.070.07 50.070.07
1.300 7.270 A FORD K71F 70.071.06 50.071.06
1.300 7.750 B FORD K72F 70.072.06 50.072.06
1.359 7.970 C DANA K103S 70.103.19 50.103.19
1.359 7.970 A
IH K101I
70.101.09 50.101.09
1.359 7.970 B
IH K102I
70.102.09 50.102.09
1.377 7.000 A MACK K75M NA
NA
1.430 8.250 B FORD K75F 70.075.06 50.075.06
1.430 8.250 B FORD K76F 70.076.06 50.076.06
1.433 8.500 B ROCKWELL KD901R 74.901.18 54.901.18
1.434 8.750 E CHEVY K95G 70.095.07 50.095.07
1.434 9.410 E ROCKWELL KD900R NA
NA
1.484 8.850 A
IH K108I
NA
NA
1.484 8.890 B
IH K109I
NA
NA
1.500 6.687 F MACK K534M NA
NA
1.500 7.150 B MERITOR K70R 70.070.18 50.070.18
1.500 7.400 F MACK K535M NA
NA
1.500 7.500 B ROCKWELL K80R 70.080.18 50.080.18
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
Bus Steering Knuckle King Pin Kits
revision date 11/2012
BLUEBIRD
All American
Airtek Softek
649505-0004
00063311
LT SIDE
00063312
RT SIDE
00063313
BT SIDES
50.121.08
12000# FF-942
B 1.794 x 10.40
K931L
70.931.12 50.931.12
12000#
I-120S, I-120SG,
I-120SGL
8305203
B 1.921 x 9.87
K120I
8
70.120.09
8
70.120.99
3,8
50.120.09
8
ST70-19
TC2000
12000#
I-120SA,
I-120IS,
I-126SA,
I-126IS
14600#
I-146SA
1990-
4294716
B 1.859 x 10.75
K146S
14000# I-140S
I-140SG, I-146
8305211
B 2.046 x 10.12
K141S
8
70.141.19
8
50.141.19
8
ST70-24
10,800#
1988-1989
2156784
4293270
B 1.609 x 9.66
K140I
70.140.09 50.140.09 ST70-5
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
continued
