STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 24
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
Bus Steering Knuckle King Pin Kits
revision date 11/2012
INTERNATIONAL / NAVISTAR,
MAN, MCI,
NEW FLYER, ROCKWELL
continued
INTERNATIONAL / NAVISTAR
10,000#, I-100S
(02-ADC)
12,000#, I-120S
(02-ADD)
B 1.921 x 9.87
K120I
8
70.120.09
8
70.120.99
3, 8
50.120.09
8
ST70-19
14,000#, I-140S
(02-ADE)
(02-AGV)
1668412C91
B 2.046 x 10.12
K141S
8
70.141.19
8
50.141.19
8
ST70-24
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
MC-7, MC-8, MC-9
15000#
16000#
2254366
IC-2-40
E 1.794 x 10.68
K170G
12
13200#
FF-941, FF-961
B 1.794 x 10.40
K961L
70.961.12 50.961.12 ST70-7
MC-12
14600#
FG-931
IJ-2-54
B 1.794 x 10.40
KG931R
77.931.18 57.931.18 ST70-7
102DL3
16000#
20000#
FH-946
01-01-1017
01-01-1079
B 1.794 x 9.19
KH946R
78.946.18 58.946.18 ST70-7
“G” Coach
16000#
I-160S
B 2.046 x 11.00
K161S
ST70-24
MAN
V8-65C-02
1993
81-44205-6013
6313078
J
1.969 x 8.77
K120N
ST70-27
MCI
NEW FLYER
MAN
6313078
J
1.969 x 8.77
K120N
ROCKWELL
17100, 17101, 17111,
17801
12000#
R201309
R201310
R201319
R201471
B 1.794 x 10.40
KG931R
77.931.18 57.931.18 ST70-7
8000#
MFS-08
R201474
B 1.500 x 7.50
K80R
70.080.18 50.080.18 ST70-28
12000#
FF-931, FF-932,
FF-933, FF-934
R200195
R201307
B 1.794 x 10.40
K931L
70.931.12 50.931.12 ST70-7
13200# FF-941,
FF-942, FF-943,
FF-944, FF-945
R201315
R201470
B 1.794 x 10.40
K961L
70.961.12 50.961.12 ST70-7
13200# FF-961,
FF-962, FF-966,
FF-967, FC-965
R201315
R201470
B 1.794 x 10.40
K961L
70.961.12 50.961.12 ST70-7
NEOPLAN
I-161
329116
B 1.794 x 11.00
K162S
ST70-7
