STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 25
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
www.stemcokaiser.com
ROCKWELL
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
ROCKWELL, THOMAS
14600#, FG-931,
FG-933, FG-941,
FG-943, FG-952
R201309
R201310
R201319
R201471
B 1.794 x 10.40
KG931R
77.931.18 57.931.18 ST70-7
16000# FH-941,
20000#
FH-945, FH-946
R201420
R201424
B 1.794 x 9.19
KH946R
78.946.18 58.946.18 ST70-7
18000# FL-931,
FL-933, FL-941,
FL-943, FL-951
R200198
R201312
B 1.999 x 11.22
KH931L
78.931.12 58.931.12 ST70-12
THOMAS
ER-Series
School Bus Chassis;
Rear Engine1
8314171
B 1.359 x 7.97
K102I
70.102.09 50.102.09 ST70-2
13,200#
FF-932
1307
B 1.794 x 10.40
K931L
70.931.12 50.931.12 ST70-7
14,600#
FG-941,
FG-944
1309
1310
B 1.794 x 10.40
KG931R
77.931.18 57.931.18 ST70-7
Alliance Axle
AF-10.0-3,
AF-12.0-3,
AF-13.0-3,
AF-13.3-3,
AF-14.7-3
P6073300019KZ
P6073300119KZ
B 1.771 x 9.23
K120A
ST70-30
