SPOT, WORK, & FLOOD LAMPS
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
114
SPE
81712
81711
81704
81702
Flood Lamps
81704
Lamp only, 12v
81714
Lamp & mount, 12v
LED
81
®
Series
7” Auxiliary Lamp
10 Diode Pattern
Material:
• Hard coated polycarbonate lens
• E-Coat aluminum housing
• Blunt cut 18 gage wire
• Encapsulated circuitry
Light Source:
• 10 LEDs
• 12V designed at 12.8V, 4.5A
• 24V designed at 28V, 1.5A
• 1300 lumens
• Overvoltage spike protection to
600v constant output
• Operating temperature range
-50°C to 70°C
Recommended Accessories:
• 00872 short bracket
• 00874 long bracket
• 00876 denim cover
Itar Regulations:
These Items Are Subject To US Export
Control Laws Export Of Such Items
May Require Prior Authorization From
The US Government, Including The
US Commerce Department’s Bureau
Of Industry And Security Or The State
Department’s Directorate Of Defense
Trade Controls Unauthorized Export,
Re-Export, Or Diversion Contrary To
US Law Is Prohibited
• US Patent #D572856, #000795034, #122406 and trademark #3483147
• Ideal for utility companies, construction, agricultural, airport and tow
trucks and state and county highway departments
• 12 volt lamp operates at full brightness between 8.5v and 16v,
over-voltage protection at 17v-18v
• 24 volt lamp operates at full brightness between 21v and 34v,
over-voltage protection at 35v-36v
• Mounts on one 5/16” stud
4.18
2.47
6.80
81360
81391
81385
81395
LED
81
®
Series
4” Auxiliary Lamp
6 Diode Pattern
Material:
• Die cast aluminum housing
• Polycarbonate lens
• Stainless steel hardware
• 18 gauge wire
• Encapsulated circuitry
Light Source:
• 6 LEDs
• 12 V designed at 12.5 V, 1.2 A
• 24 V designed at 24 V, 0.5 A
• 500 lumens
Replacement Parts:
• 97432 hardware pack
Work Lamp w/Black Finish
81360
Lamp, 12v
81371 Lamp, 12v w/20’ Lead
81240 Lamp, 24v
Work Lamp w/Chrome Finish
81365 Lamp, 12v
81245 Lamp, 24v
Work Lamp w/White Finish
81374
Lamp, 12v
81270 Lamp, 24v
Spot Lamp w/Black Finish
81390 Lamp, 12v
81290
Lamp, 24v
Spot Lamp w/Chrome Finish
81395
Lamp, 12v
81295
Lamp, 24v
Spot Lamp w/White Finish
81391 Lamp, 12v
Flood Lamp w/Black Finish
81380
Lamp, 12v
81250
Lamp, 24v
Flood Lamp w/Chrome Finish
81385 Lamp, 12v
81255 Lamp, 24v
• Popular auxiliary lighting for off-road, utility, construction applications and more
• Provides LED, solid-state solution to applications in need for additional lighting,
resistant to damage from shock and vibration
• Two mounting options: one with an integrated mount and one designed for use with
a secondary mounting bracket (sold separately)
• Use of advanced white LED technology exceeds light output of HID lights, with no
EMI and substantially longer life than comparable incandescent lamps, saving time
and expense of replacing lamps multiple times
• Metalized reflector redirects light output effectively increasing visibility
• Hard-wired design and fully encapsulated electronics protect from damage caused
by corrosive element
• Impact resistant, non-yellowing, headlamp-grade polycarbonate lens protects
against damage caused by debris and other hazards
81714
81701
00876
Work Lamps
81702 Lamp only, 12v
81712
Lamp & mount, 12v
Spot Lamps
81701 Lamp only, 12v
81711
Lamp & mount, 12v
