111 / 348
DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
109
Super 10
®
Utility
Sealed
Material:
• Polycarbonate lens
& housing
Light Source:
• 15,000 hr. rated bulb life
• Designed at 14v, 0.33 amp,
2cp
Recommended Accessories:
• Mounting: Pages 249-252
• Plugs: Page 225-228
1.75”
4.75”
.197”MIN
LED
80
®
Series Dome
6 Diode Pattern
Material:
• Clear polycarbonate lens
• Steel housing
Light Source:
• 6 Light Emitting Diodes (LEDs)
• Designed at 13.5v, 0.40 amps,
100 lumens
Recommended Accessories:
• 973lens
• Surpasses 2,000 hours of incandescent
bulbs by nearly 50x
• As much as 60% lower power consumption
than incandescent lamps, allowing additional
power for other vehicle applications
80162C Lamp w/blunt cut wire
80164C Lamp w/.180 bullet connectors
80166C Lamp w/blunt cut, 24v
2.535
1.000
2.540
.700
• Unique shock-mount extends bulb life
• 15,000 hour rated bulb life
• Standard PL-10 connection
10209C Clear lamp
10
®
Series Utility
Sealed
Material:
• Polycarbonate lens
& housing
Light Source:
• 15,000 hr. rated bulb life
• Designed at 14v, .33 amp,
2cp
Recommended Accessories:
• Mounting: Pages 249-252
• Plugs: Page 225-228
• Lens & housing are sonically sealed
• High impact polycarbonate construction
• 15,000 hour rated bulb life
• Replaces Signal-Stat 1010W
10202C Clear lamp 10204C Clear lamp, 24v
.690
2.000
1.20
2.490
.830
See page 92
30
®
Series Utility
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• 15,000 hr. rated 12v bulb life
• 12v designed at 14v, 0.33 amp,
2 cp.
• 24v designed at 28v.,
.17 amp, 3 cp
Recommended Accessories:
• Mounting: Pages 253-255
• Plugs: Page 225-228
• High impact polycarbonate construction
• Lens & housing are sonically sealed
• 15,000 hour rated bulb life
• Replaces Signal-Stat 1030W
30200C Clear lamp
30206C Clear lamp, 24v
15
®
Series Utility
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Designed at 14v, .33 amp,
2 cp
Recommended Accessories:
• Mounting: Pages 256-257
• Plugs: Page 225-228
• High impact
polycarbonate sonically
sealed lens & housing
• Features 15,000 hour
long life bulb
• Replaces Signal-Stat
1500W
15200C Clear lamp
