SPOT, WORK, & FLOOD LAMPS
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
117
SPE
8140
8192
8180
8193
LED
Economy Work
Lamps
4, 8 Diode Pattern
Material:
• Hard-coated polycarbonate
heated lens
• eCoat aluminum housing and
internal structures
• Metalized reflector
• Stainless steel bracket mount
• 20-inch, 18-gauge wire with blunt
cut ends
Light Source:
• 8140
4 LEDs
700 lumens
10-30v Multi-volt design: .64a at
12v, .33a at 24v
• 8180
8 LEDs
1400 lumens
10-30v Multi-volt design: 1.3a at
12v, .7a at 24v
Additional Specifications:
• Operating temperature range: -40
to 65
• Flood pattern
LED
Economy Pillow
Optic Work Lamps
5, 8 Diode Pattern
Material
• Hard-coated acrylic lens
• eCoat aluminum housing
• Metalized reflector
• Stainless steel bracket mount
• 15-inch, 18-gauge wire with blunt
cut ends
Light Source
• 8192:
5 LEDs
1200 lumens
10-30 V Multi-volt design:
12 V, 1.13 A
24 V, 0.56 A
• 8193
8 LEDs
1900 lumens
10-30 V Multi-volt design:
12 V, 1.58 A
24 V, 0.84 A
Additional Specifications:
• Operating temperature range:
-30 to 50
• Heavy-duty housing is constructed of die cast aluminum
• Lens manufactured with impact resistant polycarbonate material
• Rear fins keep heat away from LEDs and lamp circuitry, allowing
for increased light output and light longevity
• White LEDs offer daylight-like visibility, cleaner and clearer than
other light source options
• Current regulated switching circuit
• Overvoltage protection
• SAE voltage shock protection
• EMC protection and IP 67 certified
• Heavy-duty housing is constructed of die cast aluminum
• Lens manufactured with impact resistant acrylic material
• Rear fins keep heat away from LEDs and lamp circuitry,
allowing for increased light output and light longevity
• White LEDs offer daylight-like visibility, cleaner and clearer
than other light source options
• Current regulated switching circuit
• EMC protection
8140 3” round work lamp, 4 diode
8180 5.5” oval work lamp, 8 diode
8192 3.5” square work lamp, 5 diodes
8193 6” oval work lamp, 8 diode
5.30
4.37
1.4
4.73
5.61
5.7
3.47
4.62
3.93
2.0
8192
8193
8140
8180
