112 / 348
DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
110
1.250
1.750
1.416
1.000
Courtesy Lamp
Sealed
Material:
• Polycarbonate lens & housing
Kit Components:
26001 lamp kit
1 - 04115 lamp w/gasket
1 - 94854 plug
• Variety of interior & exterior
applications
• Compact sealed
polycarbonate construction
26001
Lamp kit
04115
White lamp w/gasket
04116
Black lamp w/o gasket
19
®
Series Utility
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Two bulbs designed at 14v,
0.33 amp, 2 cp each
Recommended Accessories:
• Mounting: Page 258
• Plugs: Page 226
1.23
3.780
.830
0.15 diameter male bullet
• High impact polycarbonate sonically sealed lens &
housing
• Features 15,000 hour long life bulb
19200C Clear lamp
2.11
4.31
40
®
Series Auxiliary
Lamp w/Angled
Illumination
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Designed at 12.8v, 2.1 amp,
32 cp
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 216-217
• Popular option on new Wabash trailers
• Uniquely designed shock mount extends lamp life
• For auxiliary use only
• Specially designed lens allows lamp to angle light
away from trailer rather than straight back
• Output light up to 10’ on sides at a 45˚ angle
• Illuminates area seen by driver through side
40207
Clear lamp
w/angled illumination
1.320
5.280
Model 80 Hook-Up
Bulb Replaceable
Material:
• Chrome-plated die cast
housing
• Acrylic lens
• 16 gauge wire
• Hardwired design
Light Source:
• Bulb: #1156
• Designed at 12.8v, 2.1 amp,
32 cp
Replacement Parts:
• 99176C clear lens kit
• Designed to illuminate area between truck & trailer
• Mounts to flat body surface with three screws
• Not intended for use as a back-up lamp
80423C Clear lamp
0.20 screw hole diameter
4.86 bolt hole circle
4.43 diameter mounting holes
