113 / 348
DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
111
Chrome Utility Lamp
Bulb Replaceable
Material:
• Chrome plated brass housing
• Acrylic lens
• 16 gauge wire
Light Source:
• Bulb: #193, 2 cp
Utility Lamp
Bulb Replaceable
Material:
• Polycarbonate housing
• Acrylic lens
• Hardwired design
Light Source:
• Bulb: #168, 3 cp
3.120
2.590
3.800
1.610
2.75
1.75
2.00
2.12
2.75
1.75
2.00
2.12
Stepwell Lamp
Bulb Replaceable
Material:
• Stainless steel housing
• Glass lens
• 16 gauge wire
Light Source:
• 26392C: 12v, 32 cp, #1076 bulb,
2 wire
• 26393C: 12v, 21 cp, #1141 bulb
• 26394C: 12v, 21 cp, #1142 bulb,
2 wire
0.25 screw hole diameter
3.00
1.50
1.25
3.50
4.81
2.00
2.00
6.00
• Glass lens holds up to extreme temperatures
• Mounts with two #10 screws on 1.625” centers
• Mounting hole requires 13/16” diameter cutout
26393C Clear lamp
26394C Clear lamp w/ground wire
26392C Clear lamp w/ground wire
433WD Clear lamp, retail pack
• Twist off lens hood for easy bulb replacement
• Lights up instrument panel & compartments• Surface mounts on 2” centers
• Grounds through mounting screws
Utility Lamp
Bulb Replaceable
Material:
• Rubber housing
• Aluminum base
• Acrylic lens
• Hardwired design
Light Source:
• Bulb: #1895, 2 cp
• Snap-in lens for easy bulb
replacement
• Vulcanized rubber housing with
aluminum base
1506W Clear lamp
Dome & Utility Lamp
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Bulb: #912, 12 cp
Replacement Parts:
• 131 switch
• Navistar replacement
• Use for dome or utility lamp
• Surface mount for easy installation
• Polycarbonate lens & housing provides durability
4094SW Clear lamp
1.25
2.06
1.00
2.62
Interior & Utility Lamp
Bulb Replaceable
Material:
• Polycarbonate lens & housing
• Hardwired design
Light Source:
• 20302 dome lamp bulb #211-
2 designed at 12.8v, 0.97
amp, 12 cp
• 20308 utility lamp bulb
#47278 designed at 13.5v,
2.10 amp, 32 cp
Replacement Parts:
• 99005C clear lens
• 80604 (#47278) bulb
• Beehive profile lens produces maximum 90° edge
lighting
• Snap-in lens for quick and easy replacement
3.120
2.590
3.800
1.610
0.25 screw hole diameter
20302 Clear lamp dome w/#211-2 bulb
20308 Clear lamp utility w/#47278
• Focused light output
• Hooded guard to stop glare
• Separate ground wire
434WD Clear lamp, retail pack
