SPOT, WORK, & FLOOD LAMPS
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
121
SPE
Universal Mount
Material:
• Synthetic rubber (TPR) housing
• Glass lens
• 18 gauge wire
Light Source:
80388 auxiliary lamp
• Bulb: #H9420 4.2 amp, 50 watts, 47,000 cp
80389 fog lamp
• Bulb: #H9415 3.1 amp, 38 watts, 12,000 cp
80394 work lamp
• Bulb: #H9411/80206 4.2 amp, 50 watts, 5,400 cp
80395 medium flood lamp
• Bulb: #H9414 4.2 amp, 50 watts, 2,700 cp
80396 wide flood lamp
• Bulb: #H9406/80205 4.2 amp, 50 watts, 1,350 cp
80397 spot lamp
• Bulb: #H9405 4.2 amp, 50 watts, 100,000 cp
Replacement Parts:
• 80205 Wide flood beam
• 80206 Trapezoid beam
• 95910 Mounting hardware
• 97989 Housing
4.50
3.75
6.50
Single Beam Flood Lamp
Material:
• Polymer housing
• Glass lens
• Free form reflector
• 16 gauge hard-wired
Light Source:
• Bulb: one #H3, 12v, 55w, 4.5 amp,
1450 lumens
Replacement Parts:
• 80571 bulb
• 97433 mounting bracket
• Clear lens increases output 30-50%
• Compact 3” x 5” design
• Performs brighter & wider than larger lamps
• Bracket allows full tilt & 360˚ rotation adjustment
• Pre-wired with bulb
80493 Lamp
6.40
3.75
6.50
• Intelligent high performance solution for
wide variety of work lamp applications
• Two beams mean twice the lighting output
of a conventional single beam unit
• For single installations, this translates to
significantcost savings while producing the
same output as two traditional lamps
• For true high performance, installation of 2
two beam lamps results in phenomenal four
lamp illumination
• Bracket allows full tilt & 360˚ rotation
adjustment
Two Beam Work Lamp
Material:
• Polymer housing • Glass lens
• Free form reflector
• 16 gauge hard-wired
Light Source:
• Bulbs: two #H3, 12v, 55w, 4.5
amp ea., 1450 lumens ea.
Replacement Parts:
• 80571 bulb
• 97433 mounting bracket
80491
80498
80498 Work lamp
80491 Flood lamp
• Durable synthetic rubber housing resists corrosion
• Includes mounting hardware
• Universal mount uses one 5/16”-18 stud
• Contains one glass rectangular sealed halogen
beam with two right angle terminals
• Fluted lens disperses light evenly
80388
Auxiliary lamp
80389
Fog lamp
80394
Work lamp
80395
Medium flood lamp
80396
Wide flood lamp
80397
Spot lamp
6.50
4.30
4.40
5/16 - 18 stud
80494 Flood lamp w/switch
80492 Spot lamp
