124 / 348
SPOT, WORK, & FLOOD LAMPS
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
122
SPE
Halogen Auxiliary Lamps
Material:
• Plastic housing
• Glass lens
• 18 gauge wire
Replacement Parts:
• 80571 12v bulb, 4.5 amp, 55 watts,
1450 lumens
• 80561 24v bulb, 3 amp, 70 watts,
1750 lumens
Halogen Auxiliary Lamps
Material:
• PVC plastic housing
• Glass lens
• 18 gauge wire
Replacement Parts:
• 80571 bulb, 4.5 amp, 55w,
1450 lumens
• 80560 bulb, 100w
• 80561 24v bulb, 3 amp, 70w,
1750 lumens
• Rugged molded PVC housing will not
break or weather – remains flexible from
-40˚ F to +120˚ F
• Advanced 55 Watt H3 bulb design
eliminates the need for expensive sealed
beam replacement
• Precision optics
• Adjustable bracket with 5/16”
610W Work lamp
612W Fog lamp
613W Driving lamp
610W
6.95
3.48
4.50
.09
• Direct Hobbs replacement
• Durable hard plastic housing will not
weather or rust
• Advanced 55 Watt H3 bulb technology
means inexpensive bulb replacement
instead of captive sealed beam
replacement
• To convert these lamps to 24 volts –
change bulb to #80561
• 1/2” adjustable hollow stud
627WD Work lamp, retail pack
628WD Spot lamp, retail pack
629WD Flood lamp, retail pack
637W Work lamp, 24v
627WD
• Excellent replacement options for
motorcycles using 4.5” auxiliary lamps
• Supplements headlamp with light that
promotes safe driving
• Hardwired adapter connects to 2005 & newer
Harley-Davidson models using 4.5 auxiliary
lamps
• Classic, but modern look when installed with
Truck-Lite’s 27270C LED headlamp
80275 LED auxiliary lamp
LED
Auxiliary Lamp
For Use in
Supplementing
Headlamps on
Motorcycles
Material:
• Hard coated polycarbonate lens
• Anodized aluminum housing
• 18 gauge wire
Light Source:
• Designed at 12.8v, 0.7a, 3.100
max candela, 280 lumens
• Overvoltage protection to 600v,
w/constant output between 9v &
15v, and automatic shutoff at
18-20v
