125 / 348
AUXILIARY
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
123
SPE
• Adds up to 5’ of valuable lighting to perimeter of vehicle, increasing visibility in
area dome or backup lighting won’t reach
• Low profile lamp protrudes only 2.5” from vehicle surface, while projecting light
far beyond lamp surface
• Rear fins keep heat away from LEDs and lamp circuity, allowing for increased light
output and lamp longevity
• Minimal electrical draw (1.2A) allows for the use of multiple lamps, without
demanding significant power from vehicle
• Hard-wired .180 bullet terminals prevent concerns for pin corrosion at lamp, and
install without the need for adapters or additional wiring connections
• Ideal for use with lift gate trailers and body vehicles
• Care should be taken to install this device so that it cannot operate while the
trailer or vehicle is in motion. Contact the Trailer/Vehicle OEM or Truck-Lite
Technical Service for assistance.
4.46”
5”
1.53”
• Fits into any standard Par 36 bulb application
• Perfect for retrofitting incandescent Par 36 lamps
to high-efficiency LED lighting
• Heavy-duty powder coating provides excellent
protection against the elements
• Die-cast aluminum housing with vertical heat sink
pull heat from the housing
80220
Lamp
80240 Lamp w/Harley
Davidson aux. passing
lamp connector
5’
162”
3.0”
8.9”
4.4”
7.4”
0.7”
2.5”
81335C Lamp
LED
Perimeter Lamp
4 Diode Pattern
Material:
• Polycarbonate Lens
• Die-Cast Aluminum Housing
• Hard-Wired 18 Gauge Wire
w/.180 Bullet Terminals
• Encapsulated Circuitry
Light Source:
• 4 Light Emitting Diodes
• Designed At 13.5V, 1.2A
365 Lumen Output
LED
Par 36
Auxiliary Lamp
8 Diode Pattern
Material:
• Polycarbonate lens
• Powder coated aluminum housing
• 18 gauge wire
Light Source:
• 8 Light Emitting Diodes
• 9V-36V Multi-volt operation
• Designed at 1.06 amp
• 500 lumens
