SNOW PLOW / ALT LAMPS
SPE
LED
Snow Plow
& ATL Lamp Kit
Material:
Headlamp:
• Polycarbonate lens
• Die cast e-coat aluminum
housing
• 1/2” bolt diameter
Front/Park/Turn Lamp:
• Polycarbonate lens
• Die cast housing
Light Source:
Headlamp:
• 2 LED Arrays
• Multi-volt design, operational
from 9 to 33 volts at 12.8v
operation, high beam function
draws 3.60a, low beam function
draws 1.80a
Front/Park/Turn Lamp:
• 21 Light Emitting Diodes
• Designed at 12.8v
Major function: 0.625a,
Minor function: 0.046a
Kit Components:
80880 kit:
1 - 80878 RH assembly
1 - 80879 LH assembly
1 - 80898 harness
• DOT compliant LED Headlamp provides a brighter, crisper and whiter light
output, closer to the color temperature of daylight, dramatically improving light
projection distance and increasing visibility
• Advanced white LED technology reduces concerns with EMI and offers
substantially longer life than comparable incandescent lamps
• Complex reflector design spreads light in a clean, more uniform pattern
• Pedestal lamp (Front/Park/Turn) features a unique LED diode array with a full
pattern appearance
• Lamps are hard wired, with fully encapsulated electronics to protect from
damage caused by corrosive elements and moisture
• Headlamp component is backed with Truck-Lite’s 3-Year Limited Warranty, Front/
Park/Turn lamp component is covered by Truck-Lite’s 2-Year Limited Warranty,
and bracketry is covered by Truck-Lite’s standard 1-Year Limited Warranty
9.47”
7.00”
15.24”
3.56”
3.10”
80880 Lighting kit
LED
Snow Plow &
ATL Lamp Kit
Material:
Headlamp
• Polycarbonate lens
• E-Coat aluminum housing
• Metalized reflector
Pedestal Lamp
• Polycarbonate lens
• Zinc die cast housing
• Encapsulated circuitry
Light Source:
Headlamp
• 2 LED arrays
• 9V-33V multi-volt
Designed At:
• 12.8V, (LB)1.8A, (HB)3.6A
• 25.6V, (LB)1A, (HB)1.8A
Pedestal Lamp
• 21 Light Emitting Diodes
• Designed at 12.8V
Major funct: 0.62A,
Minor funct: 0.46A
Kit Components:
80875 kit:
1 - 80874 RH assembly
1 - 80873 LH assembly
1 - 80898 harness
4.5”
10.2”
14.2”
• Provides a robust, LED, solid-state solution to applications in need of durable
lighting that can withstand shock and vibration, popular for utility/municipality
use, as LED design draws less current and allows more power for other vehicle
requirements
• Advanced white LED technology eliminates EMI and offers substantially longer life
than comparable incandescent lamps
• Complex reflector design spreads light in a clean, more uniform pattern
• Pedestal lamp features a unique LED diode array with a full pattern
• Both lamps are hard wired, with fully encapsulated electronics to protect from
damage caused by corrosive elements and moisture
• Brighter and crisper light output, improving light projection distance and increasing
visibility
• DOT compliant, high beam and low beam performance
80875 Lighting kit
