126
SNOW PLOW / ALT LAMPS
SPE
LED
60
®
Series
Auxiliary Lamp
6 Diode Pattern
Material:
• Polycarbonate lens & housing
• Encapsulated Circuitry
Light Source:
• 6 Light Emitting Diodes (LED)
• Designed at 13.5v, 0.78A
• 450 Cool lumens
• 432 Warm lumens
Recommended Accessories:
• 60700 grommet
• 60703 grommet cover
• 94759 plug
• 180˚ coverage adds valuable lighting inside and outside of the vehicle, increasing
visibility in areas dome/backup lighting won’t reach
• Optic-free lens allows for smooth ambient distribution of light
• Lens/Housing constructed of high-grade, impact-resistant polycarbonate
• White LEDs offer daylight-bright visibility, cleaner and clearer than other light source
options
• Minimal electrical draw (0.78A) allows for the use of multiple lamps, without demanding
significant power from vehicle
• Fit into Truck-Lite 60 Series footprint, allowing for a simple retrofit of existing
incandescent lamps as well as the use of existing 60 Series accessories
• Less current draw, resulting in increased battery and alternator life while allowing more
power for other vehicle requirements
• Fit N’ Forget® connection for increased corrosion resistance
• Perfect for lighting instruments beneath vehicle
Lamp is for auxiliary purposes only. 60 Series LED Auxiliary Lamp is not to be used as a
back-up lamp. Care should be taken to install this device so that it cannot operate while
the trailer or vehicle is in motion. Contact the Trailer/Vehicle OEM or Truck-Lite Technical
Service for assistance.
60354C Lamp
Universal Snow Plow & ATL Kit
Material:
• Glass headlamp lens
• Polycarbonate park/turn lens
& housing
• Steel mounting bracket
• 16 gauge wire
Light Source:
• Headlamp bulb #9007, HB5, 12v
• Park/turn bulb #1157a, 5-8 DC bayonet
designed at 14v, 2.10/.59 amps
Kit Components:
80893 kit:
1 - 80895 LH/driver side
1 - 80896 RH/driver side
1 - 80831 universal wire
harness
1 - 80844 mounting hardware/
switch components
Replacement Parts:
• 27010 glass headlamp assembly
• 80895 LH/lamp assembly
• 80896 RH/lamp assembly
• 80831 universal wire harness
• 80844 hardware
• Incorporates complex reflector technology to help reduce driver fatigue
• Increased beam pattern output & improved beam pattern formation
• High impact polycarbonate & steel construction
• Features high beam/low beam halogen headlamps & integrated park/
turn lamps
• Mounts on one 1/2” - 13 stud
• Lamp functions as a snow plow lights, all terrain light or off-road/
auxiliary lights
• Kit also includes switch & wiring harness kit
80893 Lighting kit
