FRONT & REAR LIGHTING
UNI
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
13
40
®
Series
Stop/Turn/Tail &
Front/Park/Turn
Bulb Replaceable
Material:
• Polycarbonate or acrylic lens & housing
• Cam-in socket assembly
• PVC grommet
Light Source:
• Bulb: #1157 bulb
Replacement Parts:
• 99010R red lens & housing
• 99010Y yellow lens & housing
• 94938 socket assembly
Recommended Accessories:
• 99010B blue lens & housing
• 99010G green lens & housing
FMVSS:
• I6,P2,P
5.50
.43
2.60
See Pages 6 - 10
• Grommet kit includes lens, housing, socket
assembly with bulb, grommet & ground screws
• Grommet features flush mounting in a 4 1/2” hole
40302R Red, grommet kit
40302Y Yellow, grommet kit
40282R
2.09
4.30
40
®
Economy
Stop/Turn/Tail & Front/
Park/Turn
Sealed
Material:
• Polycarbonate lens & housing
• ABS flange
• PVC grommet
• 16 gauge wire
Light Source:
• Designed at 12.8 V,
2.1/.48 A
• Dual filament bulb rated at
32/2 cp
Kit Components:
40028R/40028Y grommet kit:
1 - 40282R/Y lamp
1 - 40700 grommet
1 - 94993 plug
Recommended Accessories:
• Mounting: Pages 259-261
• Plugs: Pages 213-215
FMVSS:
• Non-reflectorized - I6,P2,P
• Reflectorized - I,S,T,A,P2
FLANGE MOUNT
LAMP ONLY
• Grommet kit features flush mounting in a 4 1/2” hole
• Flange kits feature a high impact plastic affixed to lamp
See Pages 6 - 10
40028R Red, grommet kit
40028Y Yellow, grommet kit
40282R Red lamp
40282Y Yellow lamp
40285R Red lamp, reflectorized
40029R Red, gray flange kit
40229R Red lamp & gray flange
