200 / 348
FLASHERS
ELE
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
198
0.43
1.190
1.340
1.190
0.25
Flasher for Ford
®
F-Series Trucks
F150, F250, F350 &
Ford Ranger
Material:
• Plastic housing
Specifications:
• 12v/5 amp max. hazard,
2.5 amp max. turn signal
• LED and incandescent
lighting systems
Replacement for:
• F150 (1999-2003)
• F250 (1999-2003)
• F250 SD (1999-2005)
• F350 (1999-2005)
• F450 (1999-2005)
• F550 (1999-2005)
• Maintains normal flash rate when used to
flash LED lamps
• Simple installation using existing plug
footprint
• Heavy-duty solid state circuitry
• Long lasting service life means lower
maintenance costs
• Designed for use with low current LED
lamps
• Compatible with trailer tow packages
• 5 pin configuration for turn and hazard
flashing
• 5-amp maximum per output
• Conforms to DOT FMVSS 108, SAE J590
and J945
• Non-audible
97283
Flasher
3.625"
2.50"
1.187"
3.0"
2.563"
Signal-Stat
®
10 Lamp Electronic
Flashers
Material:
• Plastic housing
• 16 gauge wire
Specifications:
• 12v flasher operates at
11v to 15v
• 24v flasher operates at
22v to 30v
• Meets FMVSS 108 and
SAE J590, J945 and
J1054 (alternating)
• Mack 47M019301P2 (SS# 250)
• Conforms to DOT and SAE specifications
• Proven to exceed 1.5 million cycles of
continuous operation at max capacity
without failure
• Certified for 10 bulb load hazard warning,
5 bulb load turn signal, plus pilot
• Polycarbonate housing and brass terminals for
superior corrosion resistance and conductivity
• For school buses or emergency vehicles
• Flashes two 75 watt sealed beams per circuit
250
12v electronic heavy duty, 2-terminal
258-4 24v transistorized, 2-terminal
256
12v alternating, 3-terminal
250
256
