DAYTIME RUNNING LAMPS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
199
ELE
Daytime Running
Lamp Systems
Daytime Running Lamp (DRL) systems have a proven safety record world wide. In fact, DRL’s have
reduced multiple vehicle accidents in Canada by 11%, Sweden by 23%, Finland by 37%, and Norway
by 40%. As a result, DRLs are now being offered by many automobile and truck manufacturers as
standard equipment. Now you can add the extra safety margin to your truck, bus, RV, or automobile
with one of these easy-to-install electronic Daytime Running Lamp Control Module Kits.
• Features state-of-the-art electronics sealed in epoxy
• Module installs easily using a three-wire design
• Relay controlled output activates low beam headlamps
at full intensity whenever the ignition is turned on
• Meets or exceeds CSA guidelines
• Covered by manufacturer’s lifetime warranty
• Do not expose to moisture, excessive engine
compartment temperature or circuit overload
• Works with most Ford, GM and Dodge vehicles
• For use with positive switching headlamps only
• Not for use with positive ground vehicles
DRL System
2.05
1.671
1.540
1.00
1.992
0.118
1.14
2.05
1.671
1.540
1.00
1.992
0.118
1.14
1.170
1.320
0.170
2.660
3.120
2.170
2.120
1.170
1.320
0.170
2.660
3.120
2.170
2.120
Heavy Duty
DRL System
• Operates low beam headlamps at reduced intensity (75%) for prolonged lamp life
• Unit features 15-second “time-in” delay and tail/ marker lamp activation
• “Park brake disable” feature locks out system when parking brake is engaged
• Electronics are sealed in epoxy for protection and are short circuit protected
• Exceeds GM and Ford’s electrical, environmental, RFI and EMI specifications, on
most vehicles
• Meets or exceeds SAE, NHTSA and CSA guidelines
• For use with positive switching headlamps only
• Not for use with positive ground vehicles
• Covered by manufacturer’s lifetime warranty
Universal Switches
and Accessories
• Mounts through 5/8” diameter hole in dashboard
• Single pole normally open circuit
• 20 amps @ 12 VDC
• Replacement red knob #07332, bulb #53
• 2 Position – Off-On
• Includes weather proof boot
• 10 amps @ 6 and 12 VDC application
• On-off switch for use with auxiliary lights and
heated mirrors
• Operates 6 to 16 volts
• 15 amp max
80594 Illuminated rocker switch
131
Push button
102
Heavy duty push pull switch
97300 DRL System, 12v
97302
Heavy Duty DRL System, 12v
