JUNCTION BOXES & RECEPTACLES
HAR
Nose Boxes
Material:
• Foam polycarbonate box
7-Way Receptacles
Surface Mount
Material:
• GE Noryl body
• Cadmium plated brass pins
• Easily installed on new trailers or as a
retrofit on existing equipment
• Chemical resistant and virtually indestructible
box
• Internal electrical contacts sealed
to eliminate corrosion
• 100% electrically pre-tested with a 40 amp
capacity
• Available with or without circuit breakers
• Color-coded trailer main cable hook-up
terminals for proper connections
5.760
4.880
4.13
3.060
6.19
.800
.410 screw hole diameter
Note: We recommend use of
rubber boots with flush
mounting receptacles.
• Easy installation on all receptacles
• Includes Noryl cover, steel hinge pin, stainless
steel spring, cotter pin & shaft retainer
• Not for use with #50805 style 7-ways
50805
50822
• Tough GE Noryl, non-conductive, corrosion
resistant body
• “Floating” type, cadmium plated brass pins
allow best alignment and long-lasting contact
with plug
• Internal connections feature a direct wired
ground
• Ring terminals are used to connect wires
• Receptacle pins prevent increased resistance
due to standard breakage caused by set
screws
• Available in standard and circuit breaker version
• Meets SAE J560 standards
• Circuits are identified by color codes &
embossed notations
5-Piece Cover
Service Kit
4.50
5.10
4.50
2.20
3.40
1.60
50860
50861
50805
Nose box, without circuit breakers
50806
Nose box, with 15 amp circuit breakers
50822
Nose box, right angle
50807
Cable grommet
50808
Cap latch repair kit, round
50809
Cover, rectangular
87845
Cable clamp repair kit
50875
Cover service kit
50860
Standard 7-way body, solid pins
50866
Receptacle w/threaded stacking studs, solid pins
50861
Standard 7-way body, split pins
50863
Receptacle w/15 amp circuit breakers, split pins
50865
Receptacle w/20 amp circuit breakers, split pins
50867
Receptacle w/threaded stacking studs, split pins
