240 / 348
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
238
JUNCTION BOXES & RECEPTACLES
HAR
Smart Box
Material:
• Plastic housing
Replacement Parts:
• 50813 solid pin
• 50898 split pin
• Eliminates the need to rewire the nose box when
replacing a damaged receptacle
• Fits standard mounting bolt pattern
• Includes 2 cable entry grommets
• Wiring remains stationary on studs inside the box
• No need to disturb wiring when replacing receptacle
• Receptacle simply plugs in and secures with 2 nuts
• Brass jumpers bridge from studs to receptacle pins
3.86
2.26
4.38
4.31
3.75
5.38
6.38
• Available in 7-way, 6-way and 4-way variations
• Compact socket design with exposed terminals for easy
installation in modern trailers
• Extended interior plug prevents damage to shell
• Integral finger grips for positive pull
Die Cast
Receptacles
Material:
• Die cast housing
2.85
3.95
1.06
2.36
1.85
50886
50886
2.85
3.95
1.18
2.32
2.24
50888
50888
2.77
3.89
1.52
2.77
1.41
1.85
50896
50896
50896
50888
50878
Smart box w/solid pins
50879
Smart box w/split pins
50875
Cover service kit
50886
4-way receptacle
50888
6-way receptacle
50896
7-way receptacle
