237
JUNCTION BOXES & RECEPTACLES
HAR
Note: We recommend
use of rubber boots
with flush mounting
receptacles.
50868
• Provides secure connection to consumer trailers through stripped wire connection or
stripped wire connection w/standard 4-pin flat molded connector
• Sealed connector to the main power harness in the truck
• Adhesive lined heat shrinks protect main harness connection to the box
• Easily replaced if necessary
• Black color blends into mounting location
• Hinge pin designed to fit tightly into hinge,
keeps lid on and reduces chance for water
to get into the connection terminals
• Easily adaptable for trailers, box trucks, retail vehicles,
and box vans w/hitch set-up
• Mounting holes in same location as current Phillips boxes
• 1/4” bolt used to mount box
50892
50882
50890
Receptacle Boots
Material:
• Natural rubber boots
4.500
5.120
4.38
1.500
4.000
2.040
4.070
1.940
.750
Adapter Boxes
Surface Mount
Material:
• GE Noryl® box
• Features molded threaded brass inserts
for receptacle mounting
• Bottom entry for standard wiring with
strain relief mechanism
• Available with back access hole to
accommodate rear entry applications
• Protects electrical connections from moisture in
flush mount applications
• Large boot fits all full sized receptacles
• Small boots fit both 2 and 3 bolt flange receptacles
with end or bottom access
Quick Connect Box
Material:
• Nylon lid & base
w/UV stabilizers
4-position Packard Electric
connector #12015797 on main
harness requires P/E connector
#12010974 on the chassis.
2.930
3.720
2.770
1.590
3.300
1.530
50872
7-Way Receptacles
Flush Mount
Material:
• GE Noryl® body
• Cadmium plated brass pins
• Tough GE Noryl, non-conductive, corrosion resistant body
with “floating” type, cadmium plated brass pins that allow
best alignment & long-lasting contact with plug
• Internal connections feature a direct wired ground
• Circuits are identified by color codes and
embossed notations
• Ring terminals are used to connect wires
• Receptacle pins prevent increased resistance due to
strand breakage caused by set screws
• Meets SAE J560 standards
• Push-on-terminal design, #50872 & 50897 compatible as
OEM replacement
50868
7-way body, 2 hole flange, solid pins
50869
7-way body, 2 hole flange, split pins
50872
7-way body, push-on, 2 hole flange, split pins
50875
Cover service kit (does not work with 50897)
5.40
4.38
4.31
3.00
3.75
1.25
5.20
2.25
5.20
96512
Box w/ boat mold
96511
Box w/o boat mold
50882
2” box, bottom access
50883
2” box, rear access
50890
Small boot, rear access
50892
Large boot
96511 96512
