56
REAR-EXIT WIRES
SIDE-EXIT WIRES
.75"
3.96"
8"
9.12"
.24"
.45"
.12"
.03"
.73"
.39"
LED
36 Series
Flex-Lite
With Non-Winged
Housing
3 Diode Pattern
Material:
• Polycarbonate lens• Over-molded hot-melt
housing/substrate
• 20 gauge wire
Light Source:
• Light emitting diodes (LEDs)
• Designed at 12.8 A, 0.03 A
(red), 0.05 A (yellow)
Recommended Accessories:
• Mounting: Page 247
FMVSS:
• P2,PC
• Provides solution that requires no mounting brackets or installation screws
• Lamps adhere directly to application surface through use of heavy-duty
adhesive backing, with an easy-to-install peel-off liner
• Rear exit and side exit wires with 0.180 male bullets are available
• Side mount options can be mounted without any mounting holes
• LEDs draw much less current, allowing more power for
other vehicle requirements
• Electronics are completely sealed in epoxy to resist damage caused
by moisture & corrosion
• Reduces lighting costs caused by physical damage & heat entrapment
• Winged housing provides option for mounting around radius corners
• Provides solution that requires no mounting brackets or installation screws
• Lamps adhere directly to application surface through use of heavy-duty adhesive
backing, with an easy-to-install peel-off liner
• Rear exit and side exit wires with 0.180 male bullets are available
• Side mount options can be mounted without any mounting holes
• LEDs draw much less current, allowing more power for other vehicle requirements
• Electronics are completely sealed in epoxy to resist damage
caused by moisture & corrosion
• Reduces lighting costs caused by physical damage & heat entrapment
LED
36 Series
Flex-Lite
With Winged Housing
3 Diode Pattern
Material:
• Polycarbonate lens• Over-molded hot-melt housing/
substrate
• 20 gauge wire
Light Source:
• Light emitting diodes (LEDs)
• Designed at 12.8v, 0.03 amp (red),
0.05 amp (yellow)
Recommended Accessories:
• Mounting: Page 248
FMVSS:
• P2,PC
36100R Red lamp, side exit wires
36100Y Yellow lamp, side exit wires
36110R Red lamp, rear exit wires
36110Y Yellow lamp, rear exit wires
36130R Red lamp, rear exit, 10-30 volt
36130Y Yellow lamp, rear exit, 10-30 volt
36105R Red lamp, side exit wires
36105Y Yellow lamp, side exit wires
36115R Red lamp, rear exit wires
36115Y Yellow lamp, rear exit wires
