64 / 348
M/C
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
62
2.25
1.35
1.35
2.93
1.06
2.93
2.25
1.06
LED
30
®
Series
Low Profile
PC Rated
2” Sealed
6 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v, 0.12 amp
Kit Components:
30086R/Y grommet kits:
1 - 30385R/Y lamp
1 - 30700 grommet
1 - 93745 plug
30091R/Y gray flange kits:
1 - 30386R/Y lamp & flange
1 - 93745 plug
Recommended Accessories:
• Mounting: Pages 253-255
• Plugs: Pages 225-228
FMVSS:
• P2,PC
• U.S. patent #6623150
• LEDs have no filament, therefore are not susceptible to shock & vibration
• Less current draw, resulting in increased battery & alternator life while
allowing more power for other vehicle requirements
• SAE PC rated for combination clearance/marker applications
LED Lamp
30385R Red
30385Y Yellow
LED Lamp
30285R Red
30285Y Yellow
LED Lamp & Gray Flange
30386R Red
30386Y Yellow
LED Lamp & Black Flange
30391Y Yellow
LED Lamp & Black Flange
30288R Red
30288Y Yellow
LED Lamp & Gray Flange
30289R Red
30289Y Yellow
LED Grommet Kits
30086R Red
30086Y Yellow
LED Gray Flange Kits
30091R Red
30091Y Yellow
