HIGH MOUNTED STOP LAMPS
SIG
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
52
LED
60
®
Series
High Mounted
Stop Lamp
26 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v, .35 amp
Kit Components:
60061R grommet kit:
1 - 60260R lamp
1 - 60700 grommet
1 - 94789 adapter plug
60062R gray flange kits:
1 - 60262R lamp & flange
1 - 94789 adapter plug
Recommended Accessories:
• Mounting: Pages 262-263
• Plugs: Pages 213-215
FMVSS:
• U2,U3
6.50
1.62
2.32
7.88
1.62
3.31
• Recommended for auxiliary brake light applications only
• Electronics completely sealed in epoxy to resist corrosion & moisture
60061R Red, grommet kit
60260R Red lamp
60062R Red, gray flange kit
60266R
60260R
1.930
.370
6.290
4.420
7.60
3.34
.92
2.55
7.60
3.34
.92
2.55
See above
Super 60
®
CHMSL
Sealed
Material:
• Polycarbonate lens &
housing
• PVC grommet
• 16 gauge wire
Light Source:
• 12v bulb designed at 1.44
amp, 21 cp & rated for 500
hours
Kit Components:
60013R grommet kit:
1 - 60213R lamp
1 - 60700 grommet
1 - 94992 right angle plug
Recommended Accessories:
• Mounting: Pages 262-263
• Plugs: Pages 213-215
FMVSS:
• U2,U3
60213R
• Features high mount stop function whencenter
mounted on the top rear of the vehicle
• Recommended for auxiliary brake light applications only
60013R Red, grommet kit
60213R Red lamp
45
®
Series
CHMSL Products
Sealed
Material:
• Polycarbonate lens &
housing
• PVC grommet
• 16 gauge wire
Light Source:
• 12v bulb designed at
1.44 amp, 21 cp
FMVSS:
• U2,U3
• Features high mount stop function
when center mounted on the top
rear of the vehicle
45207R Red lamp
60262R Red lamp & gray flange
60266R Red lamp & black flange
