Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
53
HIGH MOUNTED STOP LAMPS
4.30
2.09
40
®
Series
CHMSL Products
Sealed
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• 12v bulb designed at 1.44 amps,
21 cp
Recommended Accessories:
• Mounting: Pages 262-263
• Plugs: Pages 213-215
FMVSS:
• U2,U3
• Features high mount stop function when center
mounted on the top rear of the vehicle
• Heavy duty shock-mounted bulb
• Recommended for use in center high mounted stop
lamp applications only
40247R Red lamp
6.00
1.28
2.03
4.80
LED
21
®
Series
High Mount Stop &
Marker Lamp
16 Diode Pattern
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• 12v lamp designed at 14v,
.18 amp (HMSL) and .03 amp
(marker/clearance)
Recommended Accessories:
• 97034 mounting gasket
• 97036 sealing gasket
FMVSS:
• U2,U3,P2
• Optional gaskets available to improve seal between lamp & body
• Electronics completely sealed in epoxy to resist corrosion
& moisture
• Hardwired design eliminates pin corrosion• Recommended for use in center high mounted stop lamp
applications only
21271R Red lamp
.1.00
9.60
.87
.3 dia.
mounting hole
• Slim lamp welcomes applications where space is at a premium
• Adhesive back adheres to mounting surface without the need for
installation screws or brackets
• Peel & stick design makes for a tight, unbreakable seal
• DOT/SAE compliant
• 96” wire lead makes wiring easier
• Recommended for use in center high mounted
stop lamp applications only
LED
CHMSL Lamp
Adhesive Mount
9 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 13.2v, .25 amp
FMVSS:
• U2,U3
92100
Red lamp
92101
Red lamp w/Packard connector
