62 / 348
M/C
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
60
1.40
2.54
3.50
1.40
• Standard lamp has 2 diodes, Omni-
Volt lamp has 3 diodes
• Less current draw, resulting in
increased battery & alternator life
• Electronics completely sealed in
epoxy to resist corrosion & moisture
LED Grommet Kits
10050R Red
10050Y Yellow
LED Gray Flange Kits
10051R Red
10051Y Yellow
LED Lamp
10250R Red
10256R Red, 10-30v
10250Y Yellow
10256Y Yellow, 10-30v
LED Lamp & Gray Flange (ABS system compatible)
10271Y Yellow, w/ ABS logo
LED Lamp & Gray Flange
10251R Red
10251Y Yellow
2.53
.708
.866
2.79
1.07
2.53
.708
.866
2.79
1.07
• Popular on owner/operator & show trucks
• Standard PL-10 connection
• Reflectorized lamp has 4 diode pattern
1050
Red
1050A Yellow
1051 Red w/clear lens
1051A Yellow w/clear lens
1052 Red w/reflectorized lens
1051A
1053
1051
1050
1052
1052A
1050A
LED
10
®
Series
2-1/2” Sealed
2-3 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14v, 0.03 amp (red)
and 0.08 amp (yellow)
Kit Components:
10050R/Y grommet Kits:
1 - 10250R/Y lamp
1 - 10700 grommet
1 - 93745 plug
10051R/Y gray flange kits:
1 - 10251R/Y lamp & flange
1 - 93745 plug
Recommended Accessories:
• Mounting: Pages 249-252
• Plugs: Pages 225-228
• 97079 flange gasket
FMVSS:
• P2
LED
2-1/2” Sealed
1-13 Diode Pattern
Material:
• Polycarbonate lens & housing
Light Source:
• Light Emitting Diodes (LED)
• Designed at 13.5v, .011 amp
Recommended Accessories:
•Mounting: Pages 249-252
• Plugs: Pages 225-228
FMVSS:
• P2
• Reflectorized - A,P2
1053
Integral flange, red
1053A Integral flange, yellow
1058 Single diode, lamp, red
1058A Single diode, lamp, yellow
1053A
1058
1058A
1052A Yellow w/reflectorized lens
1070 Red w/gray flange
1070A Yellow w/gray flange
1071 Red w/clear lens, gray flange
1071A Yellow w/clear lens, gray flange
