97 / 348
LICENSE LAMPS
LIC
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
95
26 Series License
Bulb Replaceable
Material:
• Polycarbonate lens
• ABS housing
• Hardwired
Light Source:
• Bulb: #67 designed at
13.5v, .59 amp, 4 cp
Replacement Parts:
• 26380 gray hood
FMVSS:
• L
2.750
1.950
2.000
1.500
1.950
2.000
1.500
26 Series License
Bulb Replaceable
Material:
• Steel housing
Light Source:
• Bulb: #67 designed at
13.5v, 0.59 amp, 4 cp
FMVSS:
• L
• Extra rugged cadmium-plated steel housing
• Screw lock cover cams on/off for easy bulb replacement
• Ideal for license, instrument or step lighting
• Surface mounts, grounds through screw
• Replaces Signal-Stat 431W
26330 Clear lamp
0.25 screw hole diameter
2.625
3.000
2.000
26 Series License
Bulb Replaceable
Material:
• Steel housing
• Hardwired
Light Source:
• Bulb: #67 designed at
13.5v, 0.59 amp, 4 cp
FMVSS:
• L(2)
• Design is similar to lamps used on GM vehicles
• Two lamps required for license plate illumination
• Rubberized single contact electrical plug
• Replaces Signal-Stat 436W
26336
Clear lamp
1.87 clearance hole
0.15 diameter male bullet
1.50
1.88
1.30
26 Series License
Bulb Replaceable
Material:
• Brass housing
• Hardwired
Light Source:
• Bulb: #67 designed at
13.5v, 0.59 amp, 4 cp
FMVSS:
• L(2)
• Features chrome-plated brass housing
• Snap-fit design uses standard 1-1/4” diameter hole
• Commonly used to illuminate a license plate on step bumpers
• Two units required for license illumination
• Ideal for courtesy, map, instrument, license or step lighting
• Snaps securely into any panel thickness up to .187”
• Replaces signal-Stat 430W
0.18 diameter male bullet
26331
White lamp
2.0
2.625
1.75
1.625
• Features high impact housing with
streamline design
• Mounts on 1-3/4” hole centers
• Replaces Signal-Stat 420W & 423W
26335 Clear lamp
Wire length 4.50
