96 / 348
LICENSE LAMPS
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
94
2.030
6.000
4.810
1.200
StandardLens
Super 21
®
License
Sealed
Material:
• Acrylic lens
• ABS housing
Light Source:
• Designed at 14v, 0.33 amp, 2 cp
Recommended Accessories:
• Plugs: Pages 223
FMVSS:
• L
• Acrylic lens & ABS housing are sonically sealed
• Unique bulb cradle shock mount absorbs shock &
vibration, prolonging bulb life
• Long life bulb is rated for 15,000 hours
• Lamp kit includes #96930 hot wire
21204C
21004C Clear kit
21204C Clear lamp
0.22 screw hole diameter
2.023
5.881
1.495
2.023
5.881
1.495
Male Pin 21
®
License
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Designed at 14v, 0.33 amp, 2 cp
FMVSS:
• L
• Features male pin connections
• Polycarbonate lens & housing withstands
impact & corrosion
• Shock mount absorbs road shock & vibration
• Replaces Grote® #60331
29204C Clear lamp
3.125
2.700
1.00
1.920
17 Series License
Sealed
Material:
• Polycarbonate lens & housing
Light Source:
• Designed at 14v, .35 amp, 3 cp
Recommended Accessories:
• Plugs: Page 225
FMVSS:
• L
0.25 screw hole diameter
0.18 diameter male bullet
17200
• High impact polycarbonate sonically
sealed lens & housing
• Designed to mount with bracket, #17720
• Horizontal mount only
17001 Clear kit w/90˚ angle hot wire (94922)
17002
Clear kit w/straight hot wire (94923)
17003
Clear kit w/bracket & hot wire (94922)
17200
Clear lamp
2.0
2.0
4.0
3.0
2.0
2.0
4.0
3.0
License Illuminator
Bulb Replaceable
Material:
• Polycarbonate lens & housing
Light Source:
• Bulb: #67, 4 cp
Replacement Parts:
• 8951W gray hood
FMVSS:
• L
• Snap-grip lens hood for easy bulb replacement
• Ideal for license, instrument, or step lighting
• Surface mount, grounds through screw
425WD Clear w/gray housing, retail pack
426W Clear w/chrome housing
426W
Wire length 7.50
10.625
3.375
2.375
4.937
10.625
3.375
2.375
• Original equipment on Airstream
• Lamp body chrome plated steel
• White painted steel license frame
• Rubber pad between lamp and frame
435W Clear lamp
Wire length 9.25
License Kit
Bulb Replaceable
Material:
• Steel housing & bracket
Light Source:
• Bulb: #67, 4 cp
Replacement Parts:
• 97296 hood
FMVSS:
• L
435W
