BRAKE HARDWARE
*Not Sold Separately
BRAKE REPAIR KITS
E-2675HD MEGA PLUS MACK WITH MERITOR 16-1/2” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3914
Roller
Antiseize Lubricate not sold
separately.
REPLACES:
Dayton/Batco 081083,
Dayton/Batco 08108300
Haldex 67356
Haldex CQ67356
Wagner 911004
Leland K77
Meritor R509406,KIT9003,
KIT9406
Sirco MK1, MK1HD
2 2
E-502
Anchor Pin
3 4
E-801
Lock Ring
4 2
E-579A
Anchor Pin Lock Screw
5 2
E-747
Spring Retainer
6 4
E-1269
Anchor Pin Seal
7 1
E-1880B
Return Spring
8 1
E-3887
Anti-Seize Compound
E-11974 MERITOR 16-1/2” P
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 4
NSS*
Snap Ring
Drive axle, Cast P series brake shoes.
Services 1 brake.
2 4
E-537
Anchor Pin Felt
3 4
NSS*
Felt Retainer
4 2
NSS*
Roller
5 1
E-5212
Return Spring
6 2
NSS*
Bushing
7 2
E-3513
Retaining Clip
8 2
NSS*
Anchor Pin
KIT-4HD MEGA PLUS MERITOR 16-1/2” “P” SERIES and STD. FORGE EARLY MODEL BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
2 2
E-11741
Roller
Contains new Posi-Plus roller.
For use with the following Brake
Shoes: E-2687 (5”), E-3418 (5”),
E-2241 (7”), E-5239 (8-5/8”),
E-2496 (10”)
REPLACES:
Dayton/Batco 081001, 081002,
081038, 081120
Haldex CQ67390
Dana/Spicer HK16, HK16XLS,
TA23A
Leland K44B, K59
Meritor KIT9002,KIT9002N,KIT901
7,KIT9017N, KIT9017NC, KIT9063,
KIT9063BK, KIT9063BULK,
KIT9063N, KIT9063NBK,
R509002, R509063
Sirco TFINT, TK4MPHD
3 1
E-1880B
Return Spring
4 2
E-3007A
Roller Retainer
5 4
E-801
Lock Ring
6 2
E-579A
Anchor Pin Lock Screw
7 4
E-1269
Anchor Pin Seal
8 2
E-747
Spring Retainer
9 1
E-3887
Anti-Seize Compound
