BRAKE HARDWARE
BRAKE REPAIR KITS
E-2676 MEGA PLUS MACK 16-1/2” OLD STYLE CAST BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-714
Brake Shoe Wear Pad For use with Mack’s own Old Style
cast shoe with wear plates
REPLACES:
Dayton/Batco 081081
Dayton/Batco 08108110
Meritor R507069
2 1
E-752
Return Spring
3 2
NSS*
Anchor Pin
4 4
E-537
Anchor Pin Felt
5 4
E-671
Felt Retainer
6 4
E-5093
Camshaft Lock Ring
7 4
E-530
Brake Shoe Bushing
E-5086 MEGA PLUS MACK WITH MERITOR 16-1/2” “Q” BRAKE WITH 50,000 LB. REAR AXLE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-5087
Anchor Pin
For use with the following Brake Shoe:
E-5092 (7”)
REPLACES:
Dayton/Batco 081115
08111500
Dana/Spicer 82A, TA82A
Haldex CQ62767
Leland K293
Meritor KIT8026HD
Sirco MK2
2 2
E-8938
Anchor Pin Bushing
3 2
E-5088
Retainer Spring
4 1
E-3490B
100 lb Return Spring
5 2
E-5089
Roller
6 2
E-3007A
Roller Retainer
7 2
E-747
Spring Retainer
8 2
NSS*
Retainer Pin Spring
9 2
E-5091
Lock Ring
10 1
E-3887
Anti-Seize Compound
