BRAKE HARDWARE
BRAKE REPAIR KITS
E-9070 MEGA PLUS MERITOR 16-1/2” “Q” BRAKE WITH “FL”SERIES fRONT AXLES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
Contains new Posi-Plus roller.
For use with the following Brake
Shoes: E-3303 (5”), E-3823 (5”),
E-3304 (6”)
REPLACES:
Dana/Spicer 80A
Haldex CQ66889
Dana/Spicer HK80XLS
Leland K366
Meritor KIT8037
Sirco MF3
2 2
E-1893
Anchor Pin Bushing
3 2
E-2767
Retainer Spring
4 1
E-9069
Return Spring
5 2
E-11741
Roller
6 2
E-747
Spring Retainer
7 2
E-3007A
Roller Retainer
E-1607HD MEGA PLUS MERITOR 16-1/2” BRAKE SHOES WITH REINFORCED ANCHOR BOSSES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-502
Anchor Pin
Contains new Posi-Plus roller.
REPLACES:
Dayton/Batco 081082,
08108200, 08108260
Dana/Spicer 192A, 19A
Haldex 67357
Wagner 911008
Haldex CQ67357
Navistar IT192A
Leland K46, K61
Meritor KIT9004, KIT9409,
R509409
Dana/Spicer M16LK104X
TA192A
Sirco TK7, TK7HD, TK7HD10
2 2
E-11741
Roller
3 1
E-1880B
Return Spring
4 2
E-3007A
Roller Retainer
5 4
E-1269
Anchor Pin Seal
6 4
E-801
Lock Ring
7 2
E-579A
Anchor Pin Lock Screw
8 2
E-747
Spring Retainer
9 1
E-3887
Anti-Seize Compound
E-9644 MEGA PLUS MERITOR 16-1/2” STEER AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For use with relocated return
spring shoes and Q Plus™
camshafts. Can also be used
on “Hammer Claw” camshaft.
Important Note: Spring must
be installed with end hook open
toward camshaft head. Contains
new Posi-Plus roller. For use with
the following Brake Shoes:
E-3823 (5”), E-9780 (6”). Double
Web “Q” Brake Shoe used on
Mack Front Axles.
REPLACES:
Dayton/Batco 08108850,
08111600, 08111630
Dana/Spicer 81A
Haldex CQ66887
Dana/Spicer HK81XLS
Leland K292, K334
Meritor KIT8081, R508053
Sirco MF1, MF2
2 2
E-1893
Anchor Pin Bushing
3 2
E-2767
Retainer Spring
4 1
E-9643
Return Spring
5 2
E-11741
Roller
6 2
E-747
Spring Retainer
7 2
E-3007A
Roller Retainer
