BRAKE HARDWARE
BRAKE REPAIR KITS
KIT-4S STOPMATE PLUS MERITOR 16-1/2” “P” SERIES and STD. FORGE EARLY MODEL BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-512
Anchor Pin
Contains new Posi-Plus roller.
For use with the following Brake
Shoes: E-2687 (5”), E-3418 (5”),
E-2241 (7”), E-5239 (8-5/8”),
E-2496 (10”)
REPLACES:
Dayton/Batco 081001,
08100100,081044, 081419,
081706, 81417
Eaton 122844, 5-2236, 52236B
Dana/Spicer 163A, 164A,
164ABULK, 16A, HK16XLS, TA23A
Haldex 67315, CQ67315
Wagner 911000
Leland K44A, K59
Meritor KIT9002, KIT9002N,
KIT9017, KIT9017N, KIT9017NBK,
KIT 9017NC, KIT9017NBULK,
R509000, R509002
Trailmobile RWKIT9017N
Sirco TK1, TK2
2 2
E-11741
Roller
3 1
E-545A
Return Spring
4 2
E-3007A
Roller Retainer
5 4
E-801
Lock Ring
6 2
E-579A
Anchor Pin Lock Screw
7 4
E-1269
Anchor Pin Seal
8 2
E-747
Spring Retainer
KIT-4SHD STOPMATE PLUS MERITOR 16-1/2" "P" SERIES and STD. FORGE EARLY MODEL BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-512S
Anchor Pin
Contains new Posi-Plus roller.
For use with the following Brake
Shoes: E-2687 (5"), E-3418 (5"),
E-2241 (7"), E-5239 (8-5/8"),
E-2496 (10"). Same as KIT-4S
except has Heavy Duty Return
Spring.
REPLACES:
Dayton/Batco 08100160,
081002, 081707
Eaton 123209, 5-2237, 52237B
Dana/Spicer 161A, 164A, 16A,
16ABULK, HK16SD
Haldex 67356, CQ67390
Trailmobile 7007200
Wagner 911003
Navistar IT163A
Leland K115, K44, K44B
Meritor R509001, R509002,
KIT9017NHD, KIT9017NHDBK
Fruehauf MBCBK0027
Sirco TK1HD
2 2
E-11741
Roller
3 1
E-1880S
Return Spring
4 2
E-3007A
Roller Retainer
5 4
E-801
Lock Ring
6 2
E-579A
Anchor Pin Lock Screw
7 4
E-1269
Anchor Pin Seal
8 2
E-747
Spring Retainer
