BRAKE HARDWARE
BRAKE REPAIR KITS
E-4691 MEGA PLUS MERITOR 15” “T” SERIES FRONT BRAKE TYPES 1 and 2
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3421A
Roller
For use with the following Brake
Shoes: E-3439 (4”)
REPLACES:
Dayton/Batco 081107
Dayton/Batco 08110700
Trailmobile 384691
Eaton 5-3387
Dana/Spicer 511A
Eaton 543238
Haldex 66919
Wagner 911031
Haldex CQ66919
Dana/Spicer HK50
Dana/Spicer HK51
Leland K260
Meritor KIT9094
Meritor R509094
Sirco RF1
Sirco RF1ARK
Sirco RF1ARKS
Dana/Spicer TA511A
2 2
E-3424
Brake Shoe Anchor Pin
3 1
E-3437
Spring
4 2
E-4961A
3/4”-16 Lock Nut
5 2
E-3427
Anchor Pin Washer
6 2
E-801
Lock Ring
7 1
E-4800
Hold Down Kit
E-11747 STOPMATE PLUS SPICER 15” and 16-1/2” HEAVY AXLE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-539
Roller Retainer
For use with Spicer Heavy Axle
brake shoes.
REPLACES:
Dana/Spicer 95A
Dana/Spicer HK95XLS
2 2
E-586
Roller
3 1
NSS*
Return Spring
4 2
NSS*
Spring
5 2
E-747
Spring Retainer
E-2740 MEGA PLUS WAGNER 15” 3-1/2” FRONT BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
NSS*
Roller
REPLACES:
Dayton/Batco 081102
Dayton/Batco 08110200
Dana/Spicer 502A
Haldex 67313
Haldex CQ67313
Wagner F79791
Dana/Spicer HK57
Leland K130
Leland L1669
Meritor R507071
2 2
NSS*
Anchor Pin
3 2
E-2723
Anchor Pin Retainer
4 8
E-2724
Guide Washer
5 4
E-2725
Spring Washer
6 4
E-2726
“C” Washer
7 1
E-979
Return Spring
8 2
E-4961A
3/4”-16 Lock Nut
*Not Sold Separately
