BRAKE HARDWARE
BRAKE REPAIR KITS
E-7232 STOPMATE PLUS BENDIX 15” 4” STEER AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 4
NSS*
Retainer Spring
For use with the following shoe:
E-7230
REPLACES:
Dayton/Batco 01382
Dayton/Batco 01383
Bendix 104623
Bendix 104624
Trailmobile 387232
Sirco FF1S
2 2
NSS*
Return Spring
E-7231 STOPMATE PLUS BENDIX 15” 4” STEER AXLE BRAKE. “FORD CARGO”
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
NSS*
Roller
For use with the following shoe:
E-7230
REPLACES:
Dayton/Batco 081140
Dayton/Batco 08114000
Bendix 104627
Dana/Spicer 70A
Haldex CQ65519
Sirco FF1
Dana/Spicer HK70
Leland K297
Meritor R507080
2 2
NSS*
Pin
3 1
NSS*
Anchor Pin
4 1
NSS*
Return Spring
5 2
NSS*
Retainer Spring
E-11493 STOPMATE PLUS SPICER 15” 4” STEER AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2767
Retainer Spring
REPLACES:
Leland K374
Meritor R507096
2 2
E-539
Roller Retainer
3 2
E-586
Roller
4 2
E-747
Spring Retainer
5 1
NSS*
Return Spring
E-3291 MEGA PLUS WAGNER 15” 4” FRONT BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3421A
Roller
For use with the following Brake
Shoes: E-2729 (4”), E-4742 (4”)
REPLACES:
Dayton/Batco 081099
Dayton/Batco 08109900
Dana/Spicer 531A
Haldex 66926
Haldex CQ66926
Wagner F97506
Leland K134
Meritor R507073
Sirco WF1
2 2
NSS*
Anchor Pin
3 2
E-2723
Anchor Pin Retainer
4 8
E-2724
Guide Washer
5 4
E-2725
Spring Washer
6 4
E-2726
“C” Washer
7 1
E-2770
Return Spring Shoe
Assembly
8 2
E-4961A
3/4”-16 Lock Nut
*Not Sold Separately
